Specifications
Ash brick making machine QT8-15:1.Power saving:30%,Fully automatic
2.Mitsubishi PLC control
3.ISO9001
4.12 months guarantee
Main Technical Parameter
| Machine dimension | 3250*2690*2720mm |
| Machine power | 46kw |
| Machine weight | 10T |
| Vibration type | Table vibration |
| Vibration frequency | 3000-4500r/min |
| Product height | 60-250mm |
| Pallet size | 1100*680*20mm |
| Product cycle | 15-18s |
Theory Output Tables
| Products | Specification | Bricks/mould | Bricks/shift | Bricks/year |
| Standard brick | 240x115x53mm | 40 | 76,800 | 23,040,000 |
| Standard block | 390x190x190mm | 8 | 15,360 | 4,608,000 |
| Porous brick | 240x115x90mm | 20 | 38,400 | 11,520,000 |
| Paving brick | 200x100x60mm | 26 | 34,112 | 10,233,600 |
Charateristic of Block Making Machine
1.Multifunction in one machine:the machine can produce porous blocks,pavement blocks,river way bricks,slope protection bricks,road blocks,square bricks.
2.Brick machine used Japan Mitsuibishi PLC control system and Delta Touch Screen.
3.Use Double high-hynamic Proportional/Directional Valves to autuomatically adjust the oil flow and pressure.
4.Buffer the hydraulic cylinder
5.Guarantee production stability
6.USe Frequency Conversional Control Tehcnology,which controls the blcok making.
7.Use heat treatment on moulds.
8.Greatly improves the using lifetime of the machine by 50%
9.The machine is compact in struction,stable in performance,convenient to operate and maintain.The investment of this project occupies small land,with little investment but benefit is high,suitable for large or medium building materials enterprise to invest.
ISO Certificate
Blocks We Can Product
More actual size of fly ash brick making machine,please contact me,glad to serve you!
Machine Showing
