Specifications
1.H07V-K cable2.Iso -9001 quality guarantee
3.Manufacture direct sale,cheap price
4.Small quantity accepted
H07V-K cable,PVC flexible cable,flexible cord
Application
H07V-K cores are principally used for panels and cabinets stranding.
Installation
Open air, or in conduits, or trunking.
Standards
HD 21.3
DIN VDE 0281 part 1;
DIN VDE 0281 part 3;
DIN VDE 0293; DIN VDE 0295
Construction characteristics
Lead free Yes
Conductor flexibility Flexible class 5
Insulation PVC
Conductor material Bare copper
Electrical characteristics
Rated Voltage Uo/U 450 / 750 V
Mechanical characteristics
Mechanical resistance to impacts Low
Cable flexibility Flexible
Usage characteristics
Maximum core temperature still 70 °C
Short-circuit maximum core temperature 160 °C
Operating temperature, range -5 .. 60 °C
Weather resistance Good
Flame retardant C2, NF C 32-070
Chemical resistance Accidental
Water proof Accidental
