Specifications
Conductors: Plain annealed stranded copperInsulation: XLPE (Cross linked polyethylene)
Bedding: PVC (Polyvinyl-Chloride)
Specification:
1.Applications: Power cable suitable for power networks, direct burial, outdoors, indoors and in cable ducts
2.Conductors: Plain annealed stranded copper
3.Conductor stranding: Class 2 – Stranded circular or circular compacted
4.Conductor identification: Brown
5.Insulation: XLPE (Cross linked polyethylene)
6.Core identification: Brown
7.Bedding: PVC (Polyvinyl-Chloride)
8.Armour/Protection: AWA (Aluminium wire armour) non-magnetic
9.Sheath/Jacket: PVC (Polyvinyl-Chloride)
10.Colour: Black
11.Voltage: 600/1000v
12.Operating temperature Maximum 90°C, Minimum bending 0°C
13.Minimum bending radius: 6 x overall diameter
(Wherever possible, larger installation radius should be used)
14.Standards: BS5467: Electric cables. Thermosetting insulated, armoured cables for voltages of
600/1000V and 1900/3300V. IEC 60502: Power cables with extruded insulation and
their accessories for rated voltages from 1kV to 30kV. Flame Propagation Test to BS
EN 60332-1-2 for single cable.
If you are considering installing in high UV exposure and/or high/low ambient
temperatures i.e. desert/arctic conditions then special sheathing may be required
|
Size Sq.mm |
Max Diameter over Conductor mm |
RT of Insulation mm |
Diameter over core mm |
RT of Bedding mm |
Diameter over bedding mm |
Diameter of armour wire mm |
Diameter Over armour mm |
Apporx Overall Diameter mm |
Weight Kg/km |
50 |
8.90 |
1.0 |
10.9 |
0.8 |
12.6 |
0.9 |
14.5 |
17.5 |
708 |
70 |
10.70 |
1.0 |
12.9 |
14.6 |
14.6 |
1.25 |
17.1 |
20.2 |
970 |
95 |
12.60 |
1.1 |
14.8 |
16.4 |
16.4 |
1.25 |
19.0 |
22.3 |
1240 |
120 |
14.21 |
1.2 |
16.7 |
18.4 |
18.4 |
1.25 |
21.0 |
24.2 |
1510 |
150 |
15.75 |
1.4 |
18.6 |
20.7 |
20.7 |
1.6 |
24.0 |
27.4 |
1930 |
185 |
17.64 |
1.6 |
20.9 |
23.0 |
23.0 |
1.6 |
26.3 |
30.0 |
2330 |
240 |
20.25 |
1.7 |
23.8 |
25.9 |
25.9 |
1.6 |
29.2 |
32.8 |
2900 |
300 |
22.68 |
1.8 |
26.4 |
28.5 |
28.5 |
1.6 |
31.8 |
35.6 |
3530 |
400 |
25.65 |
2.0 |
29.8 |
32.3 |
32.3 |
2.0 |
36.4 |
40.4 |
4690 |
500 |
28.80 |
2.2 |
33.3 |
35.8 |
35.8 |
2.0 |
39.9 |
44.2 |
5740 |
630 |
32.76 |
2.4 |
37.7 |
40.2 |
40.2 |
2.0 |
44.3 |
48.8 |
7150 |
800 |
37.05 |
2.6 |
42.4 |
45.3 |
45.3 |
2.5 |
50.4 |
55.4 |
9070 |
1000 |
41.60 |
2.8 |
47.3 |
50.2 |
50.2 |
2.5 |
55.3 |
60.6 |
11120 |
