ACSR Conductor IEC Code A1/S1A ,A1/S1B
- Qingdao or others
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | Sanhe | |
| Model Number | ACSR | Insulation Material | Other, Non | |
| Type | High Voltage | Application | Overhead | |
| Conductor Material | Aluminum | Jacket | Other, Non |
Product Description
ACSR conductor consists of a solid or stranded steel core surrounded by strands of aluminium (E.C. GRADE). ACSR CONDUCTOR is available in a wide range of steel varying from as low as 6% to as high as 40 %. The higher strength ACSR CONDUCTORS are used for river crossings, overhead ground wires, installations involving extra long spans etc.. Against any given resistance of conductor
Specifications
ASTM B232/B232M-99 ACSR
| Size | stranding & wire diameter | Approximate overall diameter | Approximate wight | ||||
| Aluminum | steel | ||||||
| Cmils or AWG | mm2 | Number | mm | Number | mm | mm | Kg/km |
| 3/0 | 85.14 | 6 | 4.25 | 1 | 4.25 | 12.75 | 344.6 |
| 4/0 | 107.2 | 6 | 4.77 | 1 | 4.77 | 14.31 | 434 |
| 1/0 | 53.52 | 6 | 3.37 | 1 | 3.37 | 10.11 | 216.6 |
| 2/0 | 67.32 | 6 | 3.78 | 1 | 3.78 | 11.34 | 272.6 |
| 2 | 33.59 | 6 | 2.67 | 1 | 2.67 | 8.01 | 136 |
| 477000 | 241.65 | 26 | 3.44 | 7 | 2.67 | 21.77 | 975.2 |
| 477000 | 241.27 | 30 | 3.2 | 7 | 3.2 | 22.4 | 1108.1 |
| 795000 | 402.56 | 26 | 4.44 | 7 | 3.45 | 28.11 | 1625.6 |
| 79500 | 402.33 | 24 | 4.62 | 7 | 3.08 | 27.72 | 1520.9 |
Zhengzhou Sanhe Cable Co.,Ltd. It was founded in 2008, which is a professional manufacturer and expoarter of cables for about 8 years, serving overseas clients only.
We have the mature technology,rich experience, good engineers, and establish business relationship with customers all over the world with good quality. Thay are from Asia, Middle East, Latin-America, etc.
We main products, including AAC, AAAC, ACSR, ABC Conductor, Concentric cable,PVC/XLPE/PE insulated Wire,Power cable
and so on.
Our Office
Our Factory
Bare conductor: AAC, AAAC, ACSR, ACAR conductor;
ABC cable: duplex,triplex, quardruplex service drop;
Concentric cable: aluminum or copper conductor, one/ two/ multi-core optional;
PVC insulation wire: solid or flexible copper conductor wire;
Power cable: PVC/ XLPE insulated armoured/ non-armoured PVC sheathed, etc.
