Specifications
AAAC willow bare cable /all aluminum alloy conductor/ overhead line cablesmall order accepted
factory direct sales
BS50182
ACSR,AAC,AAAC overhead cable,bare conductor is widely used in the overhead power distribution system and is is one of the
main product for forming electrified wire network.
(1) all aluminium conductor (AAC)
(2) all aluminimum alloy conductor(AAAC)
(3) aluminum conductor steel reinforced (ACSR)
(4) anti-corrosion type ACSR
(5) aluminimum conductor aluminimum clad steel reinforced(ACSR/AW)
(6)rear earth aluminimum conductor steel reinforced(ACSR/RE)
(7)aluminimum conductor aluminimum alloy reinforced(ACAR)
AAAC willow bare cable /all aluminum alloy conductor/ overhead line cable is comply with BS 50182
- staranding no.: 7
- wire diameter: 4.04mm
- overall diameter:12.12mm
nominal area:89.73mm2
approximate weight: 245.4kg/km
rated strength : 8.44kn
DC resistance at 20 ℃: 0.3665Ω/km
current rating: 233A
- Are your company a factory?
Yes, we are a manufacture with rich experience. Our facory are located in zhengzhou,henan province, the center of China. And the transportation is convenient .
- How can I get the samples?
It's our pleasure to offer you the samples .We'd like to supply samples according to your requirement.
- What's the MOQ?
The MOQ is different as the size and type of wire and cable is differnent. Pls feel free to contact me to confirm it.
- What's your market?
Our products are mainly exported to the Middle-east, South Asia,Europe,Africa,North-America,South-America etc.
- What's the standard of your products?
Our products are comply with the GB,IEC,ASTM,DIN,BS standard etc.We can also produce according to our customer's special requirement.
If you want to know more information about AAAC willow bare cable /all aluminum alloy conductor/ overhead line cable , pls feel free to contact me.
