Home > Products > AAAC Conductor > AAAC Ash Conductor/High Conductivity Aluminum Series/6000 Series Cable/ 8000 Series Aluminum
AAAC Ash Conductor/High Conductivity Aluminum Series/6000 Series Cable/ 8000 Series Aluminum
- QINGDAO OR SHANG HAI
- T/T
You May Like
-
AAAC Conductor Mulbery /High Conductivity Aluminum Series Conductor/8000 Series Aluminum
-
AAAC Oak /6000 Series Conductor/8000 Series Conductor/High Conductivity Aluminum
-
AAAC Willow/AAAC Cable /aluminum Cable/aluminum Conductor/ 6000 Series Conductor/8000 Series
-
AAAC Holly /aluminum Conductor/ HD Aluminum/ Bare Conductor/manufacturer
-
AAAC Pine From BS 50182/bare Conductor/ Overhead Cable/Chinese Manufacturer
-
AAAC Hazel BS EN 50182 /electrical Cable/conductor Wire/power Cable /aluminum Wire
Product Details
| Place of Origin | Henan, China | Brand Name | sanhe | |
| Model Number | AAAC | Insulation Material | Other, NONE | |
| Type | High Voltage | Application | Overhead | |
| Conductor Material | Aluminum | Jacket | Other, none |
Product Description
AAAC Ash conductor/High conductivity aluminum series/6000 series cable/ 8000 series aluminum
ZHENGZHOU SANHE CABLE CO.,LTD.
A,Specifications
a.High tensile strength
b.Long life
c.Light in weight
d.Suitable for high as well as extra high overhead voltage lines
B,Standard: ASTM B232 ,IEC61089, BS215 part2, DIN48204, BS EN50182, GB/T 1179-2008
C,Brief Description:
AAAConductor may be manufactured for having a wide range of tensile strength as per requirement.
The principal advantage of these conductors are high tensile strength and light weight with longer spans as well as
with lesser supports. Due to the greater diameter of ACS Conductor a much higher corona limit can be obtained causing
big advantages on high as well as extra high voltage overhead lines.
D,Applications:
Used as bare overhead transmission cable and as primary and secondary distribution cable.
AAAC Conductor offers optimal strength for line design. Variable steel core stranding enables
desired strength to be achieved without sacrificing ampacity.,AAAC Conductor are used extensively
for overhead ground wires, river crossings etc. These AAAC Conductor are available with us in various types for
meeting the exact requirements of the clients.
E,Package:In coils, wooden drums, steel drums or steel-wooden drums.
We could producing according to the customers' requirements.Welcome your request for any quotations!
Code Words |
AWG |
Stranding |
Mass |
Rated Strength | DC Resistance at 20 ℃ | |
|
| No. | mm | Kg/km | KN | Ohm/km |
|
| 61 | 3.90 | 1999 | 207 | 0.04597 |
|
| 61 | 3.78 | 1878 | 194 | 0.04893 |
|
| 61 | 3.65 | 1751 | 181 | 0.05248 |
|
| 61 | 3.51 | 1620 | 167 | 0.05675 |
|
| 61 | 3.38 | 1502 | 156 | 0.0612 |
Greelely |
| 37 | 4.02 | 1289 | 135 | 0.07133 |
Flint |
| 37 | 3.59 | 1028 | 107 | 0.08944 |
Elgin |
| 19 | 4.71 | 908.3 | 97 | 0.1012 |
Darien |
| 19 | 4.36 | 778.3 | 83.1 | 0.1181 |
Cairo |
| 19 | 3.98 | 648.6 | 69.2 | 0.1417 |
Canton |
| 19 | 3.66 | 548.5 | 58.6 | 0.1676 |
Butte |
| 19 | 3.26 | 435.1 | 46.5 | 0.2112 |
Alliance | 0000 | 7 | 4.77 | 343.2 | 37.8 | 0.2678 |
Amherst | 000 | 7 | 4.25 | 272.5 | 30 | 0.3373 |
Anaheim | 00 | 7 | 3.78 | 215.6 | 23.8 | 0.4264 |
Azusa | 0 | 7 | 3.37 | 171.3 | 18.9 | 0.5365 |
Ames | 2 | 7 | 2.67 | 107.5 | 12.4 | 0.8547 |
Alton | 4 | 7 | 2.12 | 67.8 | 7.83 | 1.356 |
Akron | 6 | 7 | 1.68 | 42.58 | 4.92 | 2.159 |
ASTM-B399 | BS3242 | DIN48021 | SS424 0814 | IEC60189 |
Akron | Box | 16mm² | 31mm² | 16mm² |
Alton | Acacia | 25mm² | 62mm² | 25mm² |
Ames | Almond | 35mm² | 99mm² | 40mm² |
Azusa | Cedar | 50mm² | 157mm² | 63mm² |
Anaheim | Fir | 70mm² | 241mm² | 100mm² |
Amherst | Hazel | 95mm² | 329mm² | 125mm² |
Alliance | Pine | 120mm² | 454mm² | 160mm² |
Butte | Willow | 150mm² | 593mm² | 200mm² |
Canton | Oak | 185mm² | 774mm² | 250mm² |
Cairo | Mulberry | 240mm² | 910mm² | 315mm² |
Darien | Ash | 300mm² |
| 400mm² |
Elgin | Elm | 400mm² |
| 450mm² |
Flint | Poplar | 500mm² |
| 500mm² |
Greeley | Sycamore | 625mm² |
| 560mm² |
| Upas | 800mm² |
| 630mm² |
| Walnut | 1000mm² |
| 710mm² |
| Yew |
|
| 800mm² |
| Totara |
|
| 900mm² |
| Rubus |
|
| 1000mm² |
| Araucaria |
|
| 1120mm² |
|
|
|
| 1250mm² |
