XC series High quality durable rock conveying belt conveyor
1. Working principle -- belt conveyer
Portable Belt conveyor for conveying bulk density of less than 1.67 / t / cubic meter,easy to dig a powder,granular, small block of low-abrasive materials and bags of materials,such as coal, gravel, sand, cement,fertilizer, and grain. Sent material temperature is less than 60 °C. The form of their captain and assembly can be determined according to user requirements,transmission can be electric drum can also beused with a drive rack drive.
2. Structure details -- belt conveyer
3. Features -- belt conveyer
1. Large capacity and Width;
2. High speed running;
3. Standard sapre parts, reliable working
4. Strong conveyor structure ,
5. Small vibrating and long lifespan for rollers.
6. Be well dustproof and waterproof .
7. High accurate steel pipes ensure the rollers/idlers running with low vibration and less noise.
4. Application -- belt conveyer
Belt conveyor is adaptable to both stationary and mobile crushing plants. It is widely used in mining, metallurgical and coal industry to transfer sandy or lump materials, or packaged materials. The transfer system can be single or multi-conveyors or combined with other transfer equipments according to various transferring requirements. And belt conveyor can be installed horizontally or aslope to meet the needs of different transfer lines.
5. Technical parameter -- belt conveyer
|
Belt Width (mm) |
Belt Length(m) / Power(kw) |
Belt Speed (m/s) |
Capacity (t/h) |
||
B400 |
≤12/1.5 |
12-20/2.2 |
20-25/3 |
0.8-2 |
40-80 |
B500 |
≤12/3 |
12-20/4 |
20-30/5.5 |
0.8-2 |
78-191 |
B650 |
≤12/4 |
12-20/5.5 |
20-30/7.5 |
0.8-2 |
131-323 |
B800 |
≤10/4 |
10-15/5.5 |
15-25/7.5 |
1.0-2 |
278-546 |
B1000 |
≤10/5.5 |
10-20/7.5 |
20-25/11 |
1.0-2 |
435-853 |
B1200 |
≤10/7.5 |
10-20/11 |
20-25/15 |
1.0-2 |
655-1284 |
1). If you want to order our products, please answer to these questions carefully. So that we can better to help you to chose the matching model.
2). What's the material will you transported, bag material or bulk material?
3). If bag material, please tell us the weight of every bag, If bulk material, please tell us the capacity?
4). What's the length and the lifting height do you required?
1.Packed by plastic film or can be designed with wooden cases according to your need.
2.Shipping also can be tailored.
Xinxiang Xianchen Vibration Machinery Co,. Ltd ,which is established in the year of 2009, located in China biggest machinery manufacture base Henan province, is a professional vibration machinery manufactures which specializes in the production of sieving equipments, conveying equipments, crushing equipments and feeding equipments as well as relevant parts. we committed to solve all kinds of sieving problem.
Why Choose Xianchen
1) International high quality certification product chain
2) Manufacturer, more reasonable price
3) Solid technical support and after-sales service
4) Uphold the principle of “Customer Supreme”
5) Exports to more than 20 countries and regions, good customers feedback
6) One-stop service, customized exclusive project feasibility report.
6. Maching process
7. Exhibition & Customers
8. Certification & Honor
1. Pre-sale service:
a. In order to let each customer know better about the performance and requirements, we provide these services
b. To send each potential customer the detailed production information and company profile
c. According the user’s different needs, we work to recommend and guide for them
d. To help them select the appropriate equipment
2. Service during sale:
a. Do good communication with customers, so that each part can exchange the information.
b. Deliver on time as per the contract clause.
3. After-sale service:
a. To track the customer’s feedback after receiving the equipment
b. Any product quality we receive, the technical personnel will guide to solve the problem
c. All the products have three guarantees
d. Provide technical exchanges
e. Do well about the work of maintenance and service.
1. How to choose the machine?
a: Customers who are familiar with technical performance and parameters can directly order.
Note: You had better send us the pictures you have ever used.
b: Customers who need us to choose the models, please follow the information, tell us:
• Name and feature of the raw material?
• What's the material will you transported, bag material or bulk material?
• What's the length and the lifting height do you required?
• If bag material, please tell us the weight of every bag, If bulk material, please tell us the capacity?
Note: You had better send us the relevant pictures about the details.
2.How many kinds of material are supported?
• All stainless steel (304, 316L)
• All carbon steel Q235
• Contact part Stainless steel
3.Is it special requirement available?
This machine also could be customized by clients' specific production line requirement.
