Technical process:
Manual Feeding——decoil——Guiding and slitting——Leveling——Code roller——Transverse shearing——unloading car(optional)
Technical requirements
1) Cutting material:Q235,08AL,Q195,stainless steel
2) Strip steel thickness: 0.5~1.0 mm
3) Strip steel width: <1250mm
4) Stacking length range:500~4000 mm
5) Steel coil ID:508 mm
6) Steel coil OD: 900~1400 mm
7) Coil weight: 5T Max
8) Max slitting strips:6pcs
9) Operation speed :5~40m/min MAX
10) Control system:whole line PLC control
11) Tolerance of cutting length:±1 m m/2 m
12) diagonal precision: +1 m m/2 m
13) Flatness: 1 m m/1m
14) Operation direction:Face console running left to right
Layout drawing:
Shenchong factory:
Trade fair with cutomers
If you have any interested in our Cut to length production line, don't hesitate to contact with me.
Leta Skype: letaguan; Cell: +86-15190308006
