QC11K-13X8000 Automatic Guillotine Plate Shearing Machine

Wuxi Shenchong Forging Machine Co., Ltd.
QC11K-13X8000 Automatic Guillotine Plate Shearing Machine thumbnail-1
QC11K-13X8000 Automatic Guillotine Plate Shearing Machine photo-1
US$ 90,000 - 185,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name SC
Model Number QC11K-13x8000
Voltage customize
Rated Power customize
Certification ISO, CE, SGS
Warranty 13 Months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.automatic plate shearing machine
2.ISO, SGS & CE certification
3.Professional factory
4.High precision
5.Beautiful design

Details of  QC11K-13x8000  automatic guillotine plate shearing machine



(1)this machine belongs to second generation of hydraulic shear, with advanced integrated hydraulic system with an excellent reliability and easy for maintenance.
(2)the shearing angle can not be changed due to the series cylinder.
(3)the rolling guide with 3-point support and improves the shearing quality.
(4)the power storage device returns steadily and quickly.
(5)the rectangular monoblock blades featuring long life with 4 cutting edges.
(6)rapidly, accurately and conveniently adjusting the blade clearance with the handwheel.
(7)the adjustable rake angle can minimize plate deformation.
(8)as the cutting beam has been designed in inner-inclined structure, it is easy for plates to fall down and the accuracy of products can also be guaranteed. Shearing in sections (adjust the time displayed on liquid crystal), shadow-line cutting.
(9)counter for the motorized back gauge, very accurate and convenient.
(10)rolling plate-support of the machine, this can reduce the hurt of the plates and reduce the conflict force.



Technical parameters of  automatic guillotine plate shearing machine



Model

Mild Steel

(450MPA)

Cutting Length

(mm)

Depth Of Throat (mm)

Back Gauge Range(mm)

Rake Angle Adjustment

Strokes Per Minute

Main Motor

(kw)

4×2000

4

2000

80

750

0.5°~2°

14

5.5

4×2500

4

2000

80

750

0.5°~2°

14

5.5

6×2500

6

2500

80

750

0.5°~1°30′

14

7.5

6×3200

6

3200

80

750

0.5°~1°30′

12

7.5

6×4000

6

4000

80

750

0.5°~1°30′

10

7.5

6×5000

6

5000

80

750

0.5°~1°30′

8

7.5

6×6000

6

6000

80

750

0.5°~1°30′

8

7.5

8×2500

8

6000

80

750

0.5°~2°

14

7.5

8×3200

8

3200

80

750

0.5°~2°

12

7.5

8×4000

8

4000

80

750

0.5°~2°

10

7.5

8×5000

8

5000

80

750

0.5°~2°

7

15

8×6000

8

6000

100

750

0.5°~2°

7

15

10×2500

10

2500

100

750

0.5°~2°30′

10

15

10×3200

10

3200

100

750

0.5°~2°30′

8

15

10×4000

10

4000

100

750

0.5°~2°30′

6

15

10×5000

10

5000

100

750

0.5°~2°30′

5

15

10×6000

10

6000

100

750

0.5°~2°30′

5

15

12×2500

12

2500

100

750

0.5°~2°30′

10

15

12×3200

12

3200

100

750

0.5°~2°30′

8

15

12×4000

12

4000

100

750

0.5°~2°30′

5

15

12×5000

12

5000

100

750

0.5°~2°30′

5

30

12×6000

12

6000

100

750

0.5°~2°30′

5

30

16×2500

16

2500

100

750

0.5°~2°30′

8

15

16×3200

16

3200

100

750

0.5°~2°30′

7

15

16×4000

16

4000

100

750

0.5°~2°30′

6

15

16×5000

16

5000

100

750

0.5°~3°

5

22

16×6000

16

6000

100

750

0.5°~3°

5

37

20×2500

20

2500

100

750

0.5°~3°

6

22

20×3200

20

3200

120

750

0.5°~3°

5

30

20×4000

20

4000

120

750

0.5°~3°

4

30

20×5000

20

5000

120

750

0.5°~3°

4

37

20×6000

20

6000

120

750

0.5°~3°

5

37

25×2500

25

2500

120

750

0.5°~3.5°

5

37

25×3200

25

3200

120

750

0.5°~3.5°

5

37

25×4000

25

4000

120

750

0.5°~3.5°

4

37

30×2500

30

2500

120

750

0.5°~3.5°

4

37

30×3200

30

3200

120

750

1°~3.5°

3

37

40×2500

40

2500

80

750

1°~4°

4

37×2
