Home > Manufacturing & Processing Machinery > Metallurgy Machinery > Hydraulic Rolling Machine,Doblado, 3-roller Rolling Machine,laminacion
Hydraulic Rolling Machine,Doblado, 3-roller Rolling Machine,laminacion
US$ 20,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Shenchong
Model Number:
SW11-8X2000
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cone Bending Machine,folding Machine,rolling Machine(4R HSS, 3R HSS)US$ 10,000 - 100,000MOQ: 1 Set -
Hydraulic Rolling Machine, Roll Bending Machine, 3-roller Rolling Machine,4roller RollingUS$ 10,000 - 25,000MOQ: 1 Set
-
3 Rollers Metal Shaping Machine,metal Shaper, Cone ShaperUS$ 10,000 - 200,000MOQ: 1 Set
-
Sheet Metal Cone Rolling (4R HSS, 3R HSS)US$ 10,000 - 100,000MOQ: 1 Set
-
SW SERIES Motorised Plate RollsUS$ 10,000 - 120,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Shenchong
Model Number
SW11-8X2000
After-sales Service Provided
Engineers available to service machinery overseas
Its upper roller do certical lift at the center symmetry position of bottom rollers through screw transmission, two bottom rollers rotating provide torque for rolling plate, through joggle of output gear of gear reducer and bottom rollrts.
The machine needs other assistant equipment for pre-bend plate end.
Main technical parameters
S.N. |
ITEM |
UNIT |
PARAMETERS |
|
1 |
Control type |
Mechanical type |
||
2 |
Max.plate thickness |
mm |
8 |
|
3 |
Max.plate width |
mm |
2000 |
|
4 |
Plate yield limit |
MPa |
σs=245 |
|
5 |
Min. dia of Max. thickness |
mm |
D=450 |
|
6 |
Rolling speed |
m/min |
5.5 |
|
7 |
Top roller dia. |
mm |
190 |
|
8 |
Bottom roller dia. |
mm |
170 |
|
9 |
Bottom rollers center space |
mm |
260 |
|
10 |
Main motor power |
Kw |
7.5 |
|
11 |
Weight |
Kg |
6000 |
|
12 |
Dimension |
mm |
4600x1050x1300 |
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2002
Factory Size
10,000-30,000 square meters
Total Employees
201 - 300 People
