3 Rollers Metal Shaping Machine,metal Shaper, Cone Shaper

3 Rollers Metal Shaping Machine,metal Shaper, Cone Shaper thumbnail-1
3 Rollers Metal Shaping Machine,metal Shaper, Cone Shaper photo-1
US$ 10,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
sc
Model Number:
SW11SNC-30x2500
Contact Supplier Request Quote Chat Now
Wuxi Shenchong Forging Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name sc
Model Number SW11SNC-30x2500
Machine Type Roller-Bending Machine
Raw Material Sheet / Plate Rolling
Material / Metal Processed Other, mild steel, stainless steel, aluminum
Power Hydraulic
Automation Automatic
Extra Services Machining
Certification Other, CE, ISO9001, SGS

The top roller can move horizontally and lift, the top roller lift for changing curvature of plate, horizontal move for symmetry of top roller and two bottom rollers axes line vertical surface, realize technics requirement of plate end bend and other bend, there is no need of pressure machine in manufacture. The machine can finish two end of plate pre-bend and shape and straighten at the same time without return. IT is the NC machine



Model Max.
Plate
Thickness
(mm)		 Max.           pre-
bending thickness
(mm)		 Max. plate width (mm) Upper roller pressure
(ton)		 Min. diameter of Max. plate thickness
(mm)		 Upper roller diameter
(mm)		 Bottom roller diameter
(mm)		 Two Bottom rollers center space (mm Motor power (KW) Weight Dimension                               L×W×H
Roller rotate Hydraulic system Bottom roller move (ton) (mm)
SW11SNC-6×2000 6 4.5 2000 25 380 205 125 160 3 2.2 1.1 7 4400×1760×1850
SW11SNC-8×2000 8 6 2000 35 450 220 135 180 4 2.2 1.1 8.4 4400×1760×1920
SW11SNC-8×2500 8 6 2500 55 500 255 145 200 7.5 4 1.1 9.5 5100×1880×2000
SW11SNC-12×2000 12 9 2000 65 500 255 150 245 7.5 4 1.1 9 4600×1880×2000
SW11SNC-12×2500 12 9 2500 75 650 270 150 245 11 4 1.5 13 5100×1920×2100
SW11SNC-12×3000 12 9 3000 75 750 290 150 245 11 4 1.5 16 6100×1950×2170
SW11SNC-16×2000 16 12 2000 75 650 260 150 245 11 4 1.5 11 4600×1920×2100
SW11SNC-16×2500 16 12 2500 100 750 300 165 270 15 5.5 1.5 14.6 5600×1950×2170
SW11SNC-16×3200 16 12 3200 130 850 320 180 300 15 5.5 2.2 22 6550×2100×2400
SW11SNC-20×2000 20 16 2000 100 750 300 165 270 15 5.5 2.2 18 5100×1950×2170
SW11SNC-20×2500 20 16 2500 130 800 330 180 300 15 5.5 2.2 20 5700×2100×2400
SW11SNC-20×3000 20 16 3000 190 950 375 200 360 22 7.5 4 22.5 6400×2150×2400
SW11SNC-25×2000 25 20 2000 130 1000 320 180 300 15 5.5 2.2 21.6 5350×2100×2400
SW11SNC-25×2500 25 20 2500 190 950 380 220 360 30 7.5 4 23 5700×2150×2460
SW11SNC-25×3200 25 20 3200 240 1100 410 235 380 30 11 4 24 6500×2150×2460
SW11SNC-30×2000 30 25 2000 190 950 380 220 360 30 7.5 4 21.4 5100×2100×2460
SW11SNC-30×2500 30 25 2500 270 1100 410 235 380 30 11 4 28 5785×2150×2460
SW11SNC-30×3200 30 25 3200 320 1400 510 260 420 37 15 5.5 4 6700×2350×2570
SW11SNC-30×4000 30 25 4000 380 1600 550 275 460 45 15 5.5 42.7 7750×2450×2900
SW11SNC-40×2000 40 32 2000 320 1200 460 260 420 37 11 4 35 5500×2250×2575
SW11SNC-40×2500 40 32 2500 380 1400 500 275 460 45 15 4 38 6200×2450×2900
SW11SNC-40×3200 40 32 3200 450 1600 560 290 500 55 15 5.5 41 6900×2450×2900
SW11SNC-40×4000 40 32 4000 580 2000 630 340 610 55 22 11 51 7900×2900×3550
SW11SNC-50×2500 50 40 2500 540 1800 610 320 580 55 15 11 44 6400×2650×3250
SW11SNC-50×3200 50 40 3200 610 2000 620 360 650 75 22 11 49 7400×2900×3550
SW11SNC-50×4000 50 40 4000 690 2000 700 380 700 75 30 11
SW11SNC-50×5000 50 40 5000 850 2500 790 420 780 45×2 37 15
SW11SNC-60×2500 60 50 2500 610 2000 650 380 700 75 30 15
SW11SNC-60×3200 60 50 3200 690 2300 710 420 780 75 30 15
SW11SNC-60×4000 60 50 4000 930 2500 780 440 820 45×2 37 15
SW11SNC-60×5000 60 50 5000 1050 3000 850 460 880 45×2 37 18.5
SW11SNC-70×3200 70 60 3200 930 2500 740 440 820 45×2 37 15
SW11SNC-80×4000 80 70 4000 1350 2800 880 520 1000 45×2 45 22
SW11SNC-100×4000 100 90 4000 1600 3500 940 560 1080 132 55 30
