Most popular and economic high-low temperature testing chamber
- 600 Set / Sets per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
SGS UL Laboratory temperature and humidity chambers With LCD Touch Panel
-
Large Test Space Large Observation Window temperature test chamber
-
High Reliability CE certification temperature humidity chamber for Aerospace
-
High Precise Energy Saving Climatic Test Chamber With SUS304 Stainless Steel
-
Programmable Environmental Test Chamber / Temperature And Humidity Test Chamber
-
Environmental Test Systems Temperature And Humidity Controlled Chambers
Product Details
| Place of Origin | Guangdong, China | Brand Name | KOMEG | |
| Model Number | KMH-408L | Usage | Industrial | |
| Theory | Temperature Controller | Accuracy | 0.5 | |
| Temperature Range | -40-150C |
Product Description
Temperature Humidity Chamber is also called environment testing machine, used to test various types of materials for their tolerances of heat, coldness, dryness and wetness. It is widely used in quality inspection of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
Most popular and economic high-low temperature testing chamber
| Environmental Temperature and Humidity Chamber | ||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | ||
| Model | KMH-L series | |
| 408L | ||
| Temp. range | -40 ºC~+150ºC | |
| Interior sizel | W(mm) | 700 |
| H(mm) | 750 | |
| D(mm) | 800 | |
| Exterior size | W(mm) | 980 |
| H(mm) | 1940 | |
| D(mm) | 1740 | |
| Power(KW) | 8.5 | |
| Weight(KG) | 420 | |
| Humidity uniformity | ±3.0%R.H | |
| Heat up time | -40ºC~+100ºC, within 45 min | |
| Pull down time | +20ºC~-40ºC , within 60 min | |
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | |
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection | |
| Control System | Balanced Temperature & Humidity Control System | |
| Refrigeration system | Air Cooled (Water Cooled Type is option) | |
| Hermetic compressor,Single stage refrigeration system | ||
| CFC-Free refrigerant(HFC-507/HFC-23) | ||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | |
| Operation model :Program or fix point running | ||
| Memory capacity :120programs,1200steps, | ||
| All repeat 999 cycles, part repeat 99 cycles | ||
| Humidity Range | 20~98%R.H | |
| Temp. constancy | ±0.5ºC | |
| Humidity constancy | ±2.5%R.H | |
| Temp. uniformity | ±2.0ºC | |
| Interior material | Stainless Steel Plate(SUS 304) | |
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |
| Ambient Temp. | +5ºC~+35ºC | |
| Wiring method | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | |
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | ||
Standard Met and Implemented:
GB/Bb T2423.2-89 high temperature test method
GB2423.1-89 test A: low temperature test method 6
GJB150.4-1986 test at low temperature
IEC60068-2-1 low temperature test method
IEC60068-2-38 temperature cycle
IEC60068-2-78 constant humidity temperature
MIL - STD - 202G - 103B humidity test
IEC60068-2-30 humidity temperature cycle
GB/T2423.3 constant humidity heat test method
1. Dedicate touch and excellent user experience
2. Unique and compact design, top grade appearance, stable performance and easy operation
3. Can simulate a wide rang of temperature and humidity environments
4. Capable of testing large components, assemblies, and finished products
5. Customized sizes and configurations available
6. One year warranties
7. Japan imported UP-10D Seamless Welding Machine, especially for copper pipe welding
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
Komeg has been the brand of Komeg Technology Industrial since 1990. We manufacture environmental simulation test equipment for quality-conscious customers. Our factory is located in Dongguan, covering an area of 5,000 square meters, with over 52 employees including 26 R&D engineers.
Besides this, we have a lot of other chamber for your reference:
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. and Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Two wing Drop Tester
Vibration Testing Machine
