Temperature Humidity Chamber is also called environment testing machine, used to test various types of materials for their tolerances of heat, coldness, dryness and wetness. It is widely used in quality inspection of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
1. Dedicate touch and excellent user experience
2. Unique and compact design, top grade appearance, stable performance and easy operation
3. Can simulate a wide rang of temperature and humidity environments
4. Capable of testing large components, assemblies, and finished products
5. Customized sizes and configurations available
6. One year warranties
7. Japan imported UP-10D Seamless Welding Machine, especially for copper pipe welding
High Precision Constant Temperature Humidity Chamber
| Technical parameters: | ||
| Environmental Temperature and Humidity Chamber | ||
| Secifications ( at +20°C room temp. Or+25°C water temp with empty load) | ||
| Model | KMH-S series | |
| 225S | ||
| Interior sizel | W(mm) | 700 |
| H(mm) | 700 | |
| D(mm) | 480 | |
| Exterior size | W(mm) | 980 |
| H(mm) | 1890 | |
| D(mm) | 1460 | |
| Weight(KG) | 330 | |
| Temp. range | -70 °C ~+150°C | |
| Humidity Range | 20 ~ 98&R.H. | |
| Temp. constancy | ±0.5ºC | |
| Humidity constancy | ±2.5%R.H | |
| Humidity uniformity | ±3.0%R.H | |
| Heat up time | -70°C ~ +100°C , within 60 min | |
| Pull down time | +20°C ~ -70°C , within 80 min | |
| Equipment Power | 9.5KW | |
| Ambient Temp. | 5ºC ~+35ºC | |
| Standard accessories | Sight window*1, cable port(port 50mm)*1, shelves*2, chamber lamp*1, power cable *2m | |
| Safety device (standard) | No fuse breaker, over pressure over heat and over current protection for compressor, | |
| Over temp. protect, over load protect of blower, dry heat protection | ||
| Control System | Balanced Temperature & Humidity Control System | |
| Refrigeration system | Air Cooled (Water Cooled Type is option) | |
| Hermetic compressor,Cascsde Refrigeration | ||
| CFC-Free refrigerant(HFC-507/HFC-23) | ||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | |
| Operation model :Program or fix point running | ||
| Memory capacity :120programs,1200steps, | ||
| All repeat 999 cycles, part repeat 99 cycles | ||
| Interior material | Stainless Steel Plate ( SUS 304 ) | |
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |
| System | Balanced & Humidity Control System | |
| Wiring method | AC 380±10 % 50Hz ,3 phase 4 wires +Ground Wires | |
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | ||
Besides this, we have a lot of other chamber for your reference:
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. and Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
Komeg has been the brand of Komeg Technology Industrial since 1990. We manufacture environmental simulation test equipment for quality-conscious customers. Our factory is located in Dongguan, covering an area of 5,000 square meters, with over 52 employees including 26 R&D engineers.
