2f Capacitor
- Ningbo/Shanghai
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Homor | |
| Model Number | CD60b | Type | Aluminum Electrolytic Capacitor | |
| Application | Power | Package Type | Surface Mount | |
| Capacitance | 50-1000uF | Rated Voltage | 110-330VAC | |
| Operating Temperature | -25-+50 |
Product Description
1.FEATURES:
CD60B basic type is a renewed product researched and developed according to ANSI/EIA 463-A/B Standard. The case is founded and pressed with Bakelite and resin. The characters of product: good insulating, strong strength, not easy to damage, well sealed terminals solid, without leakage, being able to withstand large outside force each direction, beautiful appearance, easy to operate, long life-span, stable parameters, reliable quality. It applies to A.C. motors with frequency 60Hz(50Hz), rated voltage 110V-330V for starting. And other fields in science and technology.
2.TECHNICAL PARAMETER:
Working temperature range | -25~+55°C |
Rated voltage range | 110~330VA |
Rated capacitance range | 21~1536μF |
Rated permissible tolerance of capacitance | 0~+20% |
Tangent of loss angle | tg&≤0.10 |
Enduring performance | according to differences of voltage and capacitance , on 0.5~4 min,last 1 sec,12500~50000times,exactly according to ANSI/EIA463-A/B Standard |
Withstand voltage between terminals | applied 1.25 times working voltage,for 2 sec,without breakdown of explosion |
Withstand voltage between terminal and Case | 2000VAC,for 10 sec,without breakdown of explosion |
3.MODEL AND DIMENSION:
ΦA | 36.50 | 46.02 | 52.38 | 65.50 |
C | 69.85-111.12 | 85.72-111.12 | 85.72-111.12 | 111.12 |
F | 12.70 | 15.88 | 22.22 | 22.22 |
Hmax | 1.50 | 1.50 | 1.50 | 1.50 |
