Zipper Bag Machine With Attachment

Specifications

Zipper Bag Machine With Attachment
zipper lock bag
bag making machine
zipper bag packing machine

Zipper Bag Machine With Attachment
zipper bag packing machine zipper lock bag
bag making machine
zipper bag packing machine



Performance and Characteristics:
1.This machine uses fully automatic servo motor with computer digital function to control length, it is easy for operation. The produced one is very tight and fast at the seals, it apparently shows a good quality.
2.Flow process of production is from rolled material through automatic edge alignment, edge trimming, strip piercing, laminating, ultrasonic compressive embossing, photo cell sensing, hole punching, thermo cutting off and ends with automatic counting, all of the operations are fully automatic.
3.This machine equips automatic stop equipment, it will work to stop the machine when it is running out of material supply or when photo cell is out of order or when temperature is losing down and below the minimum required.

Main Technical Variables

Machine model	TPM-600	TPM-800
Material	LDPE-PP-PPE	LDPE-PP-PPE
Capacity	50~150 (Cycle/min)	50~130 (Cycle/min)
Cutting width	100~500 mm	120~600 mm
Cutting length	120~600 mm	150~800 mm
Thickness of film	0.04~0.15 mm	0.04~0.15 mm
Film annulus diameter	φ500×1200 mm	φ500×1600 mm
Step motor	1kw	1kw
Transducer motor	1.5kw	2.2kw
Heater	3kw	3.5kw
Food-out motor	0.25kw	0.37kw
Ultrasonic	1set	1set
Conveying electrical	0.55kw	0.75kw
Food film motor	0.55kw	0.75kw
Sealing capacity	10-30m/min	10-30m/min
Cooling	0.37kw	0.37kw
Power	15kw	17kw
Overall dimension (L×W×H)mm	8500×1800×1800	8650×1900×1800
Voltage	50Hz 220v	50Hz 220v
Press empty machine	1900×1850×1700	2100×1850×1700
Packing dimension (L×W×H)mm	1700×1500×1900	1900×1500×1900

the product that the machine maked
