Detailed Product Description
Mini Type HDPE/LDPE Film Blown Extruder/Blown Film Machine/Blown Film Extruder is used to produce small width film.
Raw Material: HDPE/LDPE/LLDPE
Extruder
Max. Layflat Width of film: 450mm
Main motor power: 7.5kw (Inverter motor)
Assistance machine power: 0.75kw
Heating power: 11kw
Diameter of die: 40mm
L/D ratio of screw: 28:1
Speed of screw: 5-100rpm
Barrel cooling: 1/6 Hp blower*2
Film thickness: 0.008-0.12mm
Output capacity: 30kg/h
Screen filter: Mechanical screen changer
Gear Box: 3 Axis, Steel Nitride Harden Gears with Oil lubrication pump.
Material of screw and barrel: Alloyed high-quality steel 38CrMoAlA with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment
Inflation head
HDPE inflation Die: 60, 80mm diameter
Cooling air blower: 1.1kw
Aluminum Alloy x 1 set (6 air inlet hose)
Take up unit
Fixed embossing roller: 600mm
Take up embossing rollers: 165mm diameter*600mm (L)
Take up motor: 0.75KW DC motor with gear reducer
Guide embossing rollers: 115mm diameter*600mm (L)
Wooden plank bubble supports and A-frame with Gusset device
Take off speed: 5-80m/min
Single winding station
Winding motor: 20kg/cm torque motor with gear reducer
Friction metal roller: 380mm diameter*600mm (L)
Manual bobbin changing and cutting
Control cabinet
1). Temperature of screw automatically controlled (3 zones)
2). Independent switches controls including amp, rpm and m/min meters for the whole machine.
Dimension (L*W*H): 4200mm*2300mm*3800mm
Weight: About 1800kg
Including
1). HDPE Inflation die
2). 600mm nip rollers with Pneumatic open and closing AC driven
3). with manual cutting and rolling changeover
4). Air compressor
5). Lip air ring
6). Heating switches, Moment motor controlling box
7). Heating loop
8). AC electromagnetic contactor Etc.
