High Precision Brick Engraving Machine With Good Price

Name: High Precision Brick Engraving Machine With Good Price
Brand: DX or OEM
SKU: 127639315
Availability: InStock

Jinan Dexian Machinery Co., Ltd.

US$ 999 - 2,499 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

CO2

Engraving Area:

300*500mm

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type CO2

Engraving Area 300*500mm

Engraving Speed 0-60000mm/min

CNC or Not Yes

Cooling Mode Water Cooling

Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Graphic Format Supported AI, BMP, DXF, PLT, Other, AI, BMP, DXF, PLT, JPG/GIF/PGN/TIF

Place of Origin Shandong, China

Brand Name DX or OEM

Model Number DX-L350

Dimension(L*W*H) 1140*770*550mm

Certification CE, ISO, UL, Other, CE, ISO, UL, FDA,CIQ

After-sales Service Provided Engineers available to service machinery overseas

high precision brick engraving machine with good price

Application:

It can work on Wood,Acrylic, Glass, Coated Metals, Ceramic,

Delrin, Cloth, Leather, Marble, Matte Board, Melamine, Paper,

Mylar, Pressboard, Rubber, Wood Veneer, Fiberglass, Painted

Metals, Tile, Plastic, Cork, Corian, Anodized Aluminum.

Why are our products better than other similar products?

1.USB Interface, U-Flash Disk Supported, Machine will read files from memory stick, you can work even without a PC.

2. CorelDraw, AutoCAD Software Included. Smooth and Precise Engraving and Cutting.

3.Red Dot Pointer. Which will tell you the laser direction.

Parameter:

Laser Power	50W(optional)
Laser Type	Hermetic CO2 glass tube
Power Supply	AC220±10% 50 HZ/AC110±10% 60HZ
Working Area	500mmx300mm--19”x12”
Max Moving Speed	0-60000mm/min
Worktable	fixed worktable(up & down worktable optional)
Transmission	HIWIN linear guide from Taiwan
Locating Precision	<0.01mm
Min Shaping Character	character:2x2mm, letter:1x1mm
Operating Temperature	5°C-35°C
Resolution Ratio	≤4500dpi
Control Configuration	DSP
Data Transfer Interface	USB(offline)
System Environment	WINDOWS 2000/WINDOWS XP/Visa/win7
Cooling Way	water cooling and protection system
Graphic Format Supported	files which CorelDraw, Photoshop, AutoCAD can identify (BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK, DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM, CMX)
Compatible Software	CorelDraw, AutoCAD
Cutting Thickness	0–10mm(depends on different materials)
Color Separation	separation of cutting up to 256 colors
Sloping Engraving	Yes, slope can be designed discretionarily
Cuts off the water supply the protection	Yes
Optional Parts	High-grade cooling system/imported focus lens/double-head/cylinder rotary attachment
