Specifications
Rotary evaporator, 50L-Borosilicate Glass (G3.3)
-Auto Lifting, Frequency Conversion
-<-0.098MPa
-Condensing Area: 1.65sqm
Description:
Rotary evaporator can form film to perform condensation, distillation and menstruum recycle under negative pressure and constant temperature. Rotary evaporator is especially applied in condensing, crystallizing and separating heat-sensitive material and recycling menstruum. Moreover, new functions of reflux extraction are added to new model of our products.
Features:
1. Efficient Integrated Tandem Dual Reflux Condenser (1.65 sqm condensing area);
2. Automatic bath lifting system, stable and safe;
3. Flask holding system ensuring easy and safe removal;
4. Ceramic Mechanical/PTFE seal assemble with excellent airproof and resistant to erosion;
5. Glass duct prevents material from reaching metallicity and pollution;
6. Modular design with high compatibility and easy maintenance;
7. G3.3 Pyrex Glass (Borosilicate) with good physical and chemical properties;
8. Frequency Conversion speed adjustment;
9. Stainless-steel head of motor, resistance to erosion and easy to unload;
10. Twin receiving flasks with balanced converter switch perform continuous discharge of material;
11. Big mouth rotary flask, easy for wash and operation;
12. PTFE Bottom Discharge Valve, No Grease pollution;
13. Epoxy Painting for Anti-Erosion Structure is optional;
14. Explosion Proof (Flame Proof) devices are optional.
Technical Information:
| Model | R5002B |
| Rotary Flask (L) | 50L/F125# |
| Receiving Flask (L) | 20L + 10L Bottom Discharge |
| Condenser Type & Area (sqm) | Integrated Tandem Dual Reflux (1.65) |
| Evaporation Efficiency (H2O) | > 9.0L/h |
| Motor Power (w) | 250 w |
| Rotary Speed (rpm) | 10 - 110 |
| Display Type Of Rotary Speed | Digital |
| Seal Type | Ceramic Mechanical/PTFE Seal Assemble (Teflon) |
| Reachable Vacuum Level (Mpa) | <-0.098Mpa |
| Vacuum Meter | Needle |
| Speed Adjustment | Frequency Conversion |
| Glassware Material | Borosilicate (Pyrex: G3.3) |
| Bath Type | Internal Heating |
| Bath Power (kw) | 6 kw |
| Temperature Range Of Bath (°C) | Room Temperature - 180°C |
| Lift Type | Automatic Lifting Of Bath |
| Lift Distance (cm) | 18cm |
| Bath Material | SUS304 |
| Dimensions Of Bath (cm) | 55x35 |
| Dimensions (cm) | 130x80x230 |
| Power | 380V/220V/5A |
| Extra Component (Optional) | Epoxy Painting |
| Extra Component II (Optional) | Explosion Proof |
Detail Picture:
Explosion Proof (Flame Proof) Technical Information:
| BXM(D) Serial Explosion Proof Distribution Box | |
| Explosion Proof Mark | EXdeIIBT6, ExdellCT6 |
| Rated Voltage | AC380V/220V/50Hz |
| Main Reflux Rated Voltage | 60A-250A |
| Protection Level | IP54, IP55 |
| Anti-erosion Level | WF1 |
1. Aluminum alloyed shell with polyester powder painted on surface by high voltage static electricity;
2. In-built high rupture circuit breaker and Frequency converter;
3. Modular Design for customized need on circuits (Flameproof Structure of Switch Box, Increased Safety Type of Bus-bar Chamber and Terminal Box);
4. Protection from overload or short-circuit.
For details, please contact us. Based on your needs, we will customize Rotary Evaporator, equipped with vacuum pump, cooling system and control system.
