Help CenterRotary Evaporator 20L Borosilicate Condenser Explosion (Flame) Proof
Related Products
-
20L Integrated Rotary Evaporator -Shensheng -Optional Explosion (Flame) ProofUS$ 6,300 - 6,400MOQ: 1 Set -
Rotary Evaporator 2L With Auto Lifting & Vertical CondenserUS$ 850 - 860MOQ: 1 Set
-
Rotary Evaporator 2L With Diagonal CondenserUS$ 620 - 650MOQ: 1 Set
-
Rotary Evaporator 2L With Vertical CondenserUS$ 750 - 770MOQ: 1 Set
-
Rotary Evaporator 2L With Motor Lifting and Vertical CondenserUS$ 685 - 695MOQ: 1 Set
Specifications
Rotary evaporator can perform condensation, distillation and menstruum recycle under negative pressure and constant pressure.Description:
Rotary evaporator can form film to perform condensation, distillation and menstruum recycle under negative pressure and constant temperature. Rotary evaporator is especially applied in condensing, crystallizing and separating heat-sensitive material and recycling menstruum. Moreover, new functions of reflux extraction are added to new model of our products.
Features:
1. Efficient Integrated Tandem Dual Reflux Condenser (1.15 sqm condensing area);
2. Automatic bath lifting system, stable and safe;
3. Flask holding system ensuring easy and safe removal;
4. Ceramic Mechanical/PTFE seal assemble with excellent airproof and resistant to erosion;
5. Glass duct prevents material from reaching metallicity and pollution;
6. Modular design with high compatibility and easy maintenance;
7. G3.3 Pyrex Glass (Borosilicate) with good physical and chemical properties;
8. Frequency Conversion speed adjustment;
9. Stainless-steel head of motor, resistance to erosion and easy to unload;
10. Twin receiving flasks with balanced converter switch perform continuous discharge of material;
11. Big mouth rotary flask, easy for wash and operation;
12. PTFE Bottom Discharge Valve, No Grease pollution;
13. Epoxy Painting for Anti-Erosion Structure is optional;
14. Explosion Proof (Flame Proof) devices are optional.
Technical Information:
| Model | R2002B |
| Rotary Flask (L) | 20L/F95# |
| Receiving Flask (L) | 10L + 5L Bottom Discharge |
| Condenser Type & Area (sqm) | Integrated Tandem Dual Reflux (1.15) |
| Evaporation Efficiency (H2O) | > 4.0L/h |
| Motor Power (w) | 180 w |
| Rotary Speed (rpm) | 10 - 110 |
| Display Type Of Rotary Speed | Digital |
| Seal Type | Ceramic Mechanical/PTFE Seal Assemble (Teflon) |
| Reachable Vacuum Level (Mpa) | 0.098Mpa |
| Vacuum Meter | Needle |
| Speed Adjustment | Frequency Conversion |
| Glassware Material | Borosilicate (Pyrex: G3.3) |
| Bath Type | Internal Heating |
| Bath Power (kw) | 4 kw |
| Temperature Range Of Bath (°C) | Room Temperature - 180°C |
| Lift Type | Automatic Lifting Of Bath |
| Lift Distance (cm) | 16cm |
| Bath Material | SUS304 |
| Dimensions Of Bath (cm) | 45x26 |
| Dimensions (cm) | 115x70x200 |
| Power | 220V/5A |
| Extra Component (Optional) | Epoxy Painting |
| Extra Component II (Optional) | Explosion Proof (Flame Proof) |
Picture:
Parameter of Glassware:
| Borosilicate (Pyrex: G3.3) | ||
| Chemical Composition (Weight%) | SiO2 | 80.7 |
| B2O5 | 12.8 | |
| Al2O3 | 2.2 | |
| CaO | <0.6 | |
| K2O Na2O |
4.0 | |
| Parameters | Linear Expansivity |
a≤32*10^(-7) |
Thermal Shock Resistance (°C) |
270 | |
| Softening (°C) | 820 | |
| Anneal (°C) | 565 | |
Highest Temperature (°C) |
Continuous Use (°C) |
510 |
Explosion Proof (Flame Proof) Technical Information:
| BXM(D) Serial Explosion Proof Distribution Box | |
| Explosion Proof Mark | EXdeIIBT6, ExdellCT6 |
| Rated Voltage | AC380V/220V/50Hz |
| Main Reflux Rated Voltage | 60A-250A |
| Protection Level | IP54, IP55 |
| Anti-erosion Level | WF1 |
1. Aluminum alloyed shell with polyester powder painted on surface by high voltage static electricity;
2. In-built high rupture circuit breaker and Frequency converter;
3. Modular Design for customized need on circuits (Flameproof Structure of Switch Box, Increased Safety Type of Bus-bar Chamber and Terminal Box);
4. Protection from overload or short-circuit.
For details, please contact us. Based on your needs, we will customize Rotary Evaporator, equipped with vacuum pump, cooling system and control system.
