Ohv 4 Stroke Single Phase ac Generator 220v

Ohv 4 Stroke Single Phase ac Generator 220v thumbnail-1
Ohv 4 Stroke Single Phase ac Generator 220v photo-1
US$ 241 - 243 MOQ: 240 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
AODISEN
Model Number:
ADS950 ADS1200 ADS2000 ADS2500 ADS3600 ADS4500 ADS5500 ADS6500 ADS8000
Contact Supplier Request Quote Chat Now
Taizhou Aodisen Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ning bo / Shang hai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name AODISEN
Model Number ADS950 ADS1200 ADS2000 ADS2500 ADS3600 ADS4500 ADS5500 ADS6500 ADS8000
Output Type Other, single phase or single phase + 3 phase
Speed 3600rpm
Frequency 50 / 60HZ
Rated Power 0.65 / 0.8 / 1.5 / 1.8 / 2 / 2.5 / 3 / 4 / 5 / 6kw
Rated Voltage 110V/220V/230V/240V/380V
Rated Current 3.7A-28.5A

ohv 4 stroke single phase ac generator 220v



Item no: ADS950 ADS1200 ADS2000 ADS2500 ADS3600 ADS4500 ADS5500 ADS6500 ADS8000





1: New type voltage meter & current meter with double protection panel

2: Light weight, compact structure, portable and easy to operate

3: Economical, low fuel consumption rate to ensure 8 hours running without refueling

4: Overload protection for safe running

5: Easy maintenance, suitable for camping, lighting and small hand tools





Technical Data & Parameter For

ohv 4 stroke single phase ac generator 220v



Model ADS950 ADS1200 ADS1800 ADS2000 ADS2500 ADS3600 ADS4500 ADS5500 ADS6500 ADS8000
Description                                                                                                                  Household Low RPM Small Generator Set
Rated A.C. Power Output 0.65kw 0.8kw 1.5kw 1.8kw 2.0kw 2.5kw 3.0kw 4.0kw 5.0kw 6.0kw
Max. A.C. Power Output 0.8kw 1.0kw 1.8kw 2.0kw 2.2kw 2.8kw 3.5kw 4.5kw 5.5kw 6.5kw
A.C.Frequency Output Options                                                                                                                                                                                                               50/60 Hz
A.C. Phase Options Single Phase Single Phase                                                                                                                              Single Phase or Three Phase + Single Phase
Rated A.C. Voltage Output Options 110 / 120V / 220V / 230V / 240 V 110 / 120V / 220V / 230V / 240 V                                                                                                     110V / 120V / 220V / 230V / 240 V / 110V+220V / 230V+400V / 240V+415V
D.C. Output                                                                                                                                                                                              12V 8.3A
Matched Gasoline Engine Model   1E45F (2hp) 1E54F (2.8hp) ADS160 (5.5hp) ADS160 (5.5hp) ADS200 (6.5hp) ADS210 (7hp) ADS210 (7hp) ADS390 (13hp) ADS390 (13hp) ADS420 (15hp)
Matched Gasoline Engine Type Single Cylinder, 2 Strokes, Forced Air Cooling Single Cylinder, 4 Stroke, Side Valve, Forced Air Cooling, Horizontal Crank Shaft                                                                                                     Single Cylinder, 4 Stroke, Forced Air Cooling, OHV, Horizontal Crank Shaft
Ignition Mode Condenser Diode Ignition Condenser Diode Ignition                                                                                                                                         Non-Contact Transistor Ignition
Starting Mode Options   Recoil Recoil                                                                                                                                                    Recoil / Electric
  Displacement   0.063L 0.087L 0.163L 0.163L 0.196L 0.21L 0.21L 0.389L 0.389L 0.42L
Fuel Tank Capacity  4L 6L 15L 15L 15L 15L 25L 25L 25L 25L
Engine Oil Capacity  0.37L 0.37L 0.65L 0.65L 0.65L 0.65L 1.1L 1.1L 1.1L 1.1L
Continuous Operating Time   6 hours 6 hours 13 hours 13 hours 13 hours 12 hours 12 hours 10hours 10hours 10hours
Min. Fuel Oil Consumption Rate   225g / kw.h 276g / kw.h 360g / kw.h 360g / kw.h 360g / kw.h 360g / kw.h 360g / kw.h 360g / kw.h 313g / kw.h 313g / kw.h
Operating noise level   45db 60db 65db 65db 65db 67db 67db 69db 74db 74db
Dimension  380mm×330mm×330mm 460mm×370mm×390mm 600mm×450mm×470mm 600mm×450mm×470mm 600mm×450mm×470mm 600mm×450mm×470mm 600mm×450mm×470mm 700mm×525mm×580mm 700mm×525mm×580mm 700mm×525mm×580mm
N.W./G.W.   19.5kgs / 20.5kgs 21kgs / 22kgs 40kgs / 41kgs 40kgs / 41kgs 41kgs / 42kgs 42kgs / 43kgs 42.5kgs / 43.5kgs
