CATV FTTH Optical digital tv Receiver (AGC) ERH1095A
Description :
ERH1000 Series product is designed for FTTH/FTTB or HFC applications. The general type ERH1085 has a normal
output level 85dBuV per-channel for TV. The enhanced type ERH1095 provide higher level, 90dBuV with -8dBm input power and 3.5% optical modulation index.
Feature
1.CATV FTTHFiber Optic Receiver
2.Good heat dissipation
3.Optical level control
4.Excellent ESD protect
5.With AGC function
Technical Specifications
Downstream signal path | General | ||
Light Wavelength | 1260 ~ 1600nm | Power Consumption | 3.2W |
Optical Input Power Range | -8 ~ +1dBm | Voltage | 12V DC |
Frequency Range | 45MHz ~ 1GHz | RF Connector(s) | F Female |
Output Level | 90dBµV (AGC) | Optical Connector(s) | SC/APC |
Flatness | ±0.5dB | Dimensions(L×W×H)(mm) | 100×80×28 |
Slope | 0dB | Weight | 0.2kg |
Return Loss | 16dB | Operating Temp. | -20 ~ 65°C |
Noise Figure | 48dB | ESD(RF) Port | 2KV |
CTB 59channels | ≥60dB |
| |
CSO 59channels | ≥60dB |
| |
