Ftth Fiber Optic Catv Receiver/mini Receiver/mini Node
Description:
ERH1000 Series product is designed for FTTH/FTTB or HFC applications. The general type ERH1085 has a normal output level 85dBuV per-channel for TV. The enhanced type ERH1095 provide higher level, 90dBuV with -8dBm input power and 3.5% optical modulation index.
AGC (Automatic Gain Control) circuits are integrated to maintain the output level l over a wide
input optical power range -8dBm~+1dBm. The function diagram is show in Figure 1.
Feature
1.CATV FTTH onu Receiver
2.Good heat dissipation
3.Excellent ESD protect
4.With AGC function
Technical Specifications
Downstream signal path |
General |
||
Light Wavelength |
1260 ~ 1600nm |
Power Consumption |
3.2W |
Optical Input Power Range |
-8~ +1dBm |
Voltage |
12V DC |
Frequency Range |
45MHz ~ 1GHz |
RF Connector(s) |
F Female |
Output Level |
90dBµV (AGC) |
Optical Connector(s) |
SC/APC |
Flatness |
±0.5dB |
Dimensions(L×W×H)(mm) |
100×80×28 |
Slope |
0dB |
Weight |
0.2kg |
Return Loss |
16dB |
Operating Temp. |
-20 ~ 65°C |
Noise Figure |
48dB |
ESD(RF) Port |
2KV |
CTB 59channels |
≥60dB |
|
|
CSO 59channels |
≥60dB |
|
|
