45~1000MHz Mini CATV CWDM FTTH Optical Receiver

45~1000MHz Mini CATV CWDM FTTH Optical Receiver photo-1
US$ 23 - 60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Eric
Model Number:
ERH1085/WD
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai /ningbo /shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Eric
Model Number ERH1085/WD

45~1000MHz Mini CATV CWDM FTTH Optical Receiver

45~1000MHz Mini CATV CWDM FTTH Optical Receiver

ERH1000/WD Series product is designed for FTTH/FTTB or HFC applications. The general type ERH1085/WD has a normal output level 85dBuV per-channel for TV. The enhanced type ERH1095/WD provides higher level, 95dBuV with -7dBm input power and 3.5% optical modulation index. Both types with WDM integrated for 1550nm video signal pass and 1310nm digital signal reflection they are very applicable for PON system.



Feature:

1.FTTH CATV optica electric receiver build in WDM
2.-8~+2dBm input
3.Output level 20dB adjustable
4.Used in PON system
5.CE and RoHS



45~1000MHz Mini CATV CWDM FTTH Optical Receiver

Downstream Signal Path

General

Light Wavelength

1550nm

Power Consumption

2.3W

Optical Input Power Range

-8 ~ +1dBm

Voltage

12V DC

Frequency Range

45MHz ~ 1GHz

RF Connector(s)

F Female

Output Level

85dBuV

Optical Connector(s)

LC/APC

Flatness

±0.5dB

Dimensions(L*W*H)(mm)

100*80*28

Slope

0dB

Weight

0.2kg

Return Loss

16dB

Operating Temp.

-20 ~ 65°C

Noise Figure

48dB

ESD(RF) Port

2KV

CTB 59channels

≥60dB



CSO 59channels

≥58dB





45~1000MHz Mini CATV CWDM FTTH Optical Receiver

45~1000MHz Mini CATV CWDM FTTH Optical Receiver



 45~1000MHz Mini CATV CWDM FTTH Optical Receiver



45~1000MHz Mini CATV CWDM FTTH Optical Receiver





45~1000MHz Mini CATV CWDM FTTH Optical Receiver





45~1000MHz Mini CATV CWDM FTTH Optical Receiver
