Specifications
1.EHA810 CATV Broad Band Subscriber Amplifier2.RO transformer
3.Imported modules
4.OEM for customers
CATV Broad Band Subscriber Amplifier EHA810
Products Description
EHA810 Broadband Subscriber Amplifier is specially suitable for trunk end and subscribe network distributing. It’s the high performance designed for the countries, apartments and the residential districts in the cities and towns.
Features
It is all made of imported modules;
Adopts RO transformer to increase the power supply’s efficiency;
Breathe mouth at the bottom to avoid forming dew;
Each input or output port has been fixed lightning cube.
Technology Parameter
Item |
Unit |
Function Parameter |
Frequency Band |
MHz |
45 ~ 550(750)(862) |
Band-in Flatness |
dB |
±0. 75 |
Min. Gain |
dB |
26 30 |
Return Loss |
dB |
≥16 |
Output Level |
dBµV |
98 102 |
Rated Gain |
dB |
21 26 30 |
Gain Adjust Range |
dB |
0 ~ -20 |
Slope Adjust Range |
dB |
3 ~ 18 |
Noise Figure |
dB |
≤10 |
CTB |
dB |
66 65 |
CSO |
dB |
71 69 |
Max. Output Level |
dB |
120 |
Signal Hum Ratio |
dB |
≥66 |
Shock Resist Voltage |
KV |
5(10/700)µS |
Power Voltage |
V |
AC220 |
Dimension |
Mm |
270(L)*190(W)*80(H) |
Functional Block Diagram
