Working principle
Integrated water treatment equipment is made of high quality carbon steel cylinder, the special structure of
the stainless steel mesh, highfrequency electromagnetic field generator, corona discharge device field
generator and so on. Activity of iron through the membrane, mechanical adjustable hole blocking and field
threedimensional integrated corona effect filter body, absorption, concentration in the actual operation of
mining the formation of various water systems and composite material hardness scale, reducing its
concentration, to control the dirt And most of the hardness scale purposes. And through specific frequency
transducer will be processed energy conversion to the media - water, the formation of magnetic polarization
of water, making it into the scale location of the sequence ions distortion occurs, when the water temperature
rises to a certain extent, treated Is a time lag of water required to return to their original state. At this stage,
into the scale of probability is very low, thus achieving the purpose of controlling the formation of the
hardness scale. Metal ions also inhibited the wall, on the Paradise system with anticorrosion.
In addition, the entire water processor in the system normal operation, you can complete the anti-fouling, corrosion, disinfection, algae, clean filter, comprehensive water quality control functions.
Performance parameters
Control of the corrosion rate: ≤0.007mm / a(carbon steel), ≤0.005mm/a(stainless steel,copper)
Anti-fouling efficiency> 98%
Rate of sterilization alga:>99%
filtration efficiency> 73% -99%,
filter fineness:50-3000μm
Circulating water flow rate:≥0.9m/s(tube pass),≥0.3(shell pass)
Pressure loss:pressure loss: <0.01-0.03Mpa
Working pressure:1.0Mpa 1.6Mpa 2.0Mpa
Medium temperature: A Grade:0-95℃ B Grade:0-70℃ C Grade:70-90℃
Mean free error time:50000 hours
Working voltage AC220V±10%,50Hz,AC380±10%,50Hz
Safety insulation voltage: 5000V
Operating temperature:0℃-55℃
Relative temperature:<95%(25℃)
Technical parameters
FAQ
Do you have certificates?
Yes , we have ISO certificate and certificate of patent
Do you have design team?
We have a professional design team provide drawings, we wait for your confirmation and production
Can you guarantee delivery time ?
Timely transport, ensure the delivery time
Are you maufacturer ?
Yes, we are the professional water treatment equipment manufacturer in china
