Used for air conditioner installation to connect indoor and outdoor air conditioner.The copper tube inside is compatible for R410a,R407c,R404a,R507and R22 refrigerants.cross linked irrdiated .
Parameter of single insulsted copper tube
specificaton |
Outer diameter of copper tube (mm) |
Inside diameter of insulation tube (mm) |
thickness of insulation tube (mm) |
1/4” |
6.35*0.5 |
Φ6.35 |
8mm-13mm |
3/8" |
9.52*0.5 |
Φ9.52 |
8mm-13mm |
1/2" |
12.7*0.6 |
Φ12.7 |
8mm-13mm |
5/8" |
15.88*0.75 |
Φ15.88 |
8mm-13mm |
3"4 |
19.05*0.8 |
Φ19.05 |
8mm-13mm |
|
8mm-13mm |
Characteristic
Alloy:Alloy
Dimension and tolerances:according to the EN12735
Internal surface:smooth and mirror- like
Excellent resistance to corrosion
Suitable for the new gas R407C and R410A
Length:3m~15m(including the length of the short copper tube)
PE heat-shrikable tube to prevent oxidation, extend the life of the aluminum tube
| Items | Test method | Result |
| Airtightness property | 4.0MP A, 5 min | No leak |
| Presure resistance | 12MP A, 1 min | No crackle |
| Bendability | Diameter 180 deg | No pleat and crackle |
Insulation tube
Outer layer of insulation is manufactured with cross linking technology that enables the product to offer excellent thermal resistance.
Packaging
plastic bag/corrugated case/customers demands
Shipping
7working days after payment
Why choose YidDu
Flexibility&Strength
- Offer more flexibility and not kink easily
- Higher wall thickness provides better tensile strength
- Able to withstand burst pressure of more than 1000psi without sign of leakage
Lightweight&Durable
- Requires less strength to bend
- Manufactured up to 1.5mm wall thickness providing superior rigidity
- Using the sane set of bending tools as copper
Swagging &Expanding
- 30%expansion from original outer diameter
- Using the same set of swagging tools as copper
Corrosion Resistance
- Water test before shipment
- Corrosion rate is more less than copper
Customerized services. The length of pipe, brass rods and wall thickness of double coil air conditioner copper pipe can be customized.
Quick response. Quotation for double coil air conditioner copper pipe will be provided within 48 hrs.
Free sample. Single coil air conditioner copper pipe can be available.
Excellent after sale service. Professional engineer with six year experience to solve your problem regarding air conditioner copper pipe.
100% compensation if any quality problem.
Dongguang YiDu Refrigeration Technology Co.,Ltd was established in 2009, specializing in the RD and manufacture of refrigeration accessories,especially the cooper/aluminum connecting pipe for air conditioner. Product arrange includes the central air-conditioner heat preservation copper tube, air-conditioning aluminum tube, air-conditioner coating tube. Due to innovative improve technology, YiDu can ensures 4 mian advantages compared with other competitors.For six years,YiDu has already built a well-earned reputation for producing the finest products with reasonable cost. Manufacture capacity can reach 4k-6k sets daily. Products have been exported to Europe, America, Japan, Middle East, Southeast Asia,and so on. Welcome to contact our sales for quotation
