Insulated double pancake coil copper tube
The copper tube can be used in all plants for air conditioning and refrigeration and it is suitable for the use of refrigerating gas consistent with copper like R407 and R410A.
Paremeter of double pancake coil copper tube
| specification | outer diameter of copper tube | inside diameter of insulation tube | thicknesss of insulation tube |
1/4”+3/8” |
6.35×0.5+9.52×0.5 |
Φ6.35+φ9.52 |
8mm-13mm |
1/4”+1/2” |
6.35×0.5+12.70×0.6 |
Φ6.35+φ12.7 |
8mm-13mm |
1/4”+5/8” |
6.35×0.5+15.88×0.75 |
Φ6.35+φ15.88 |
8mm-13mm |
3/8”+5/8” |
9.52×0.5+15.88×0.75 |
Φ9.52+φ15.88 |
8mm-13mm |
3/8”+3/4” |
9.52×0.5+19.05×0.8 |
Φ9.52+φ19.05 |
8mm-13mm |
1/2”+3/4” |
12.70×0.6+19.05×0.8 |
Φ12.7+φ19.05 |
8mm-13
|
1.O.D.1/4’’&3/8’’,1/4’’&1/2’’,1/4’’&5/8’’,3/8’’&5/8’’,3/8’’&3/4’’,1/2’’&3/4’’
2.Wall thickness of copper tube:0.5mm-1.2mm
3.O.D of copper tube and thickness can order according to the demand of customer.
4.Length:3m-30mm(customized)
Testing on the copper tube
| Items | Test method | Result |
| Airtightness property | 4.0MP A, 5 min | No leak |
| Presure resistance | 12MP A, 1 min | No crackle |
| Bendability | Diameter 180 deg | No pleat and crackle |
Insulation tube
1.Extruded and Closed cell white polyethylene with a white outside PE-protection layer;
2.Average Density: 33Kg/m3;
3.Heating Conduction at 00≤0.033W/MK;C
4.Working Temperature from -400C until +1200C;
5.Vapor Resistance: μ>5000;
6.White external non toxic and resistance to external chemical agents and ultra-violate rays;
7.RoHS Certificate Approved.
Plastic bag and corrugated case
To be adjusted as per specific requirement
1 The length of pipe, brass rods and wall thickness of double coil air conditioner copper pipe can be customized.
2 Quick response. Quotation for double coil air conditioner copper pipe will be provided within 48 hrs.
3 Free sample of single coil air conditioner copper pipe can be available.
4 Professional engineer with six year experience to solve your problem regarding air conditioner copper pipe.
5 Excellent afer sale severce, 100% compensation if any quality problem.
Dongguang YiDu Refrigeration Technology Co.,Ltd was established in 2009, specializing in the RD and manufacture of refrigeration accessories,especially the cooper/aluminum connecting pipe for air conditioner. Product arrange includes the central air-conditioner heat preservation copper tube, air-conditioning aluminum tube, air-conditioner coating tube. Due to innovative improve technology, YiDu can ensures 4 mian advantages compared with other competitors. A First class cutting machine would not hurt pipes, avoiding narrowing size, leakage or water drop. B Excellent welder with gas bar, makes sure the inside of pipe completely empty, no occlusion, meanwhile keep original size. C 100% no aluminum slag. D OEM service, the length and wall thickness of airconditioning pipe or insulation pipe can be customized. For six years,YiDu has already built a well-earned reputation for producing the finest products with reasonable cost. Manufacture capacity can reach 4k-6k sets daily. Products have been exported to Europe, America, Japan, Middle East, Southeast Asia,and so on. Welcome to contact our sales for quotation
