thermal paper slitting machine
Automatic Thermal Paper Slitting Machinery
Specifications | |
Category |
Automatic Thermal Paper Slitter and Rewinder Machine |
Application Material |
Thermal Paper, Cash Register Paper, Fax Paper, ATM Paper, Bond Paper, Non-woven Cloth Caronless Paper,Concern Paper,Queuing Paper,Air Ticket Paper,,Boarding Paper, Film Paper,Movie Paper,etc |
Applicable Width of Axial / Material |
500-900mm / 20”-36” (or as your request |
Min. Width of Slitting |
30mm/1.2” |
Max. Machine Speed |
150m/min |
Max. Unwinding Diameter |
1000mm /40” |
Max. Rewinding Diameter |
200mm/8’ (or as your request) |
Tolerance of Slitting Width |
±0.1mm(Depending on kinds of material applied) |
Max Applicable Weight of Material |
1000 Kg |
Rated Frequency |
50Hz & 60Hz |
Rated Voltage |
380V,415V, 440V, 460V, 480V, Dual-Voltage (or as your request) |
Unwinding/Rewinding Shaft |
3” Pneumatic Air Expanding Shaft(or as your request) |
Overall Dimensions |
2050*1600*1500mm |
Weight |
1500kg |
Components | |
Unwinding Section |
-3”air expanding rewinding shaft -Automatic lift-up loading system via motor -Electromagnetic Brake from Taiwan -Fully automatic tension controller |
Slitting Section |
-Disc cutter -Cutter with adjustable and movable blade base. -Meter counter |
Rewinding Section |
-0.5”,1”,1.5”,2” or as your request -Center Rewinding technology -Pressure roller -Electromagnetic Clutch from Taiwan |
Controlling Section |
-Siemens PLC & HMI from Germany -All the parameters are displayed on the monitor -Low voltage electrical appliances all from Schneider |
Trimmed Waste Edge |
-Edge Waste Blower with Expulsion Tube |
Optional |
-Max. Jumbo roll is up to 3 reels. |
Environmental Restriction | |
Location |
Indoor. The product should be installed on flat and solid foundation. |
Voltage Regulation |
±10% |
Frequency Regulation |
±5% |
Ambient Temperature Range |
-5°C~40°C |
Altitude |
Not exceed 1000 Meters |
Relative Humidity |
Less than 85% RH (Non-Condensation) |
Configuration | |||
Name |
Model |
Pieces |
Remark |
Computer System |
PLC+HMI |
1set |
Siemens from Germany |
Main motor |
1 set |
Siemens from Germany |
|
Frequency inverter |
1Piece |
Innovance from China |
|
Air Pressure Valve |
1 set |
SMC from Japan |
|
Cylinder |
2Piece |
AIRTAC from Taiwan |
|
Air Expanding Shaft |
1 Piece |
||
Magnetic Brake |
1set |
From Taiwan |
|
Low Voltage Electrical Switch |
CHINT |
||
Relay |
Omron from Japan |
||
CONTACT INFORMATION:
WENZHOU QIANGTUO MACHINERY CO.,LTD(RUIAN WEIGUO MACHINERY CO.,LTD)
CONTACT PERSON: MISS KIKI
TEL:0086-577-63708801
MOBILE:0086-13306877870
FAX:0086-577-63708832
SKYPE:qtmachine
WEBSITE:
