Specifications
SJ-50x2 Double-color Striped Blown Film Machinery:1. die head
2. rewind unit
3. film color: 2 colors
SJ-50x2 Double-color Striped Blown Film Machinery
double color film blowing machine, film blowing machine extruder, blowing film machine, blown film machine, film blowing machinery
Use:
The Double Die Head Two-Colour Striped Film Blowing Machine Set is composed with two screw stemsand cylinder with onedie head, it adopts the device of two different plastic materials, which can blow different kinds of striped vest bags (shopping bag), it can get colorful bags without pringting ,with such features as beautiful colors, average stripe, logical structure, advancedtechnology, even rewinding and high output.
Characteristics Paremeter:
Type |
SJ-45×2 |
SJ-55×2 |
Diameter of Screw |
45mm×2 |
55mm×2 |
Screw L/D Ratio |
28:1 |
28:1 |
Screw Spead |
10-110r/min |
10-110r/min |
Max.Output(kg/h) |
45kg/h |
60kg/h |
Max.Layflat Width (mm) |
550mm |
650mm |
Film Thickness(mm) |
0.006-0.10mm |
0.006-0.10mm |
Power of Main Motor |
11kw |
18.5kw |
Total Power |
30kw |
40kw |
Weight of Machine |
2200kg |
3000kg |
Overall Dimensions(L×W×H)mm |
4800×2200×3600 |
5000×2400×4200 |
Machine photos:
Production:
Progressing plant:
Main plant:
