3SJ-G Three Layer Co-extrusion HDPE & LDPE Blown Film Machine

Name: 3SJ-G Three Layer Co-extrusion HDPE & LDPE Blown Film Machine
Brand: Qiangtuo
SKU: 127448795
Availability: InStock

US$ 50,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Wenzhou Qiangtuo Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed PE

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Zhejiang, China

Brand Name Qiangtuo

Model Number 3SJ-G

Voltage 380V

Power(W) 42KW

Dimension(L*W*H) 7000x4000x9000 mm

Weight 6T

Certification CE,ISO9001

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. we use one of the best motor in the world
2. we use one of the best inverter in the world
3. our machine has good output

Product Description

3SJ-G Three layer co-extrusion rotary die film blowing machine

three layer film blowing machine, film blowing machine extruder, blowing film machine, blown film machine, film blowing machinery

Characteristics Paremeter:

Model	3SJ-G1000	3SJ-G1200	3SJ-G1500
Screw Diameter	50×2 , 55×1	50×2 , 55×1	55×2 , 60×1
Screw Ratio L/D	30:1	30:1	30:1
Screw Speed	15-150r/min	15-150r/min	15-150r/min
Main Motor Power	15Kw×2, 18.5Kw×1	15Kw×2 ,18.5Kw×1	18.5Kw×2, 20Kw×1
Extrusion Output(Single)	80kg/h	100kg/h	120kg/h
Diameter of Die	250	300×1	400×1
Diameter of air ring	780	900	1000
Single-sided Thickness of Film	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max. Folding Width of Film	1000mm	1200mm	1500mm
Power of blower	3kw	3kw	3kw
Air compressor power	2.2kw	3kw	5.5kw
Take-up roller length	1100mmx180	1300mmx180	1700mmx180
Take-up power	1.5kw	1.5kw	2.2kw
Rotary die head power	0.55kw	0.55kw	0.55kw
Double winder power	10N/m x 3	12n/m x3	16N/m x3
Electric Total Capacity	76Kw	88Kw	102Kw
Overall Dimension	6600×4100×6000mm	6800×4300×7000mm	7000×4800×8000mm
Weight of Machine	6T	6T	6T
