SJ-65-FM600 Double Head Film Blowing Machine

Name: SJ-65-FM600 Double Head Film Blowing Machine
Brand: Qiangtuo
SKU: 127448705
Availability: InStock

US$ 10,000 - 15,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Wenzhou Qiangtuo Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed PE

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Zhejiang, China

Brand Name Qiangtuo

Model Number SJ-65-FM600

Voltage 380V

Power(W) 30KW

Dimension(L*W*H) 4800X1900X4100 mm

Weight 2T

Certification CE,ISO9001

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. One screw , one gear box , double head , can make two roller films in the same time . the output is twice as much as normal.

Product Description

SJ-65-FM600 Double head film blowing machine

double head film blowing machine, film blowing machine extruder, blowing film machine, blown film machine, film blowing machinery

Characteristics Paremeter:

Model	SJ-65Fm-600	SJ-75FM-700	SJ-85FM-800
Diameter of screw	65mm	75m	80mm
Screw Ratio (L/D)	28:1	28:1	28:1
Screw Speed	10-110r/min	10-110r/min	10-110r/min
Max.Output	65kg/h	80Kg/h	100Kg/h
Max.Folding width of Film	600mm x 2	700mm x 2	800mm x 2
Single-sided Thickness of Film	0.006-0.10mm	0.006-0.10mm	0.006-0.10mm
Power of Main Motor	22Kw	37Kw	45kw
Total Power	35Kw	60Kw	75Kw
Weight of Machinery	2800kg	3200kg	3800kg
Overall Dimensions	4800 x 3000 x 3500mm	5000 x 3400 x 3600mm	5200 x 3800 x 4000mm
