Specifications
1)5 axis 5 heads brush tufting machine2)Widely brush production range drilling machine
3)Make toilet brush and radial brush
Yangzhou Haixing CNC brush machine Co., Ltd. is a research, design, production, maintenance, sales and system integration of high-tech enterprise. We were founded in September 1995, with professional standards in the field of automation and sophisticated technology, the rapid rise in the brush machine area. Relying on technology and development and continuing to provide users with high-tech products are our constant pursuit. In the full introduction of foreign advanced technology, we based on the successful start of high-speed toothbrush tufting machine, five axis three head drilling and tufting machine, five-axis five head drilling and tufting machine, high-speed flat tufting machine, high-speed flat drilling and tufting machine and so on.
Our service purpose is the best quality, the best price, the best after sale service.
5 Axis Drilling and Tufting Combination Brush Make Machines
Technical characteristics:
1.Bored with three drilling head and two tufting head, high-speed processing, high-volume, cost-effective
2. This machine can produce many different kinds of brushes or brooms which have different filling angles, by changing specific platform
3. Bored with three high speed drilling head: hole diameter from 3.0mm up to 6.0mm,and tufting tools from min. 3.0mm up to 6.0mm
4.Hair by: round nails or flat nails.
5.Three kinds of the optional platform type:
1), platform for radial, parallel and radial/parallel tufted brushes.
2), platform for bowl brushes and semi-spherical brushes (such as toilet brushes and “Swedish style” dish-washing brushes)
3), platform or rollers and hair brushes
6.PLC and touch panel control system of man-machine, Chinese and English display, simple to understand.
7.Allow to save as 1000 procedure and easy for the creation of new models
8.Wearing parts and spare parts are standardized designs to reduce hair mechanic technology dependence.
9.Ore machine can produce either one color or two color brush, and also drill or tuft separately.
Technical parameters
Maximum production speed: up to 900 holes/minute
The maximum filament length: 240mm
Dia. Of tufting holes: 3.0mm-6.0mm
Machine size: 2.8m*1.85m*2.2m (length * width * height)
Power consumption: 5KW
Driving motor: AC Servo motor
Power Supply: three-phase 380V
Weight (KG):3500KGS
This machine can make brushes, like below:
We have professional technician and equipments.
Q: Are you factory? Where are your factory?
A: yes, our factory is about 2 hours from shanghai by train. Welcome to visit our factory.
Q: Can you teach us how to use this machine?
A: yes, sure.
Q: How can we know if our brush sample can be made by your machine?
A: You can send us brush sample, then we can use our machine to make samples for you.
Why choose us?
1.we are honest and reliable,we won't hope we only have one cooperation chance.
2.We are professional,there are a good team of engineers and designers in our factory.
3.We always stick to provide our customers best quality,best price,best service to all our customers.
4.We follow up every one customer that how is our machine working and engineer available to offer service overseas.
Any query, please feel free to contact us.
skype: jennypangjdhd QQ:986224583
