Full-Auto Automatic glass bottle washer

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	Modern pack	Model Number	XP-B
Voltage	380 or by order	Processing Types	bottle

Product Description

1.Brief introduction

XP-B type of bottle washer mainly consists of inner brusher (main body), out- brusher (auxiliary device) and steeper. Main body of this machine drives two sets of dialing wheel, which moves intermittently, to feed bottles and wash inner surface of bottles. At the same time, auxiliary device washes outside surface of bottles with its five brushes, which arranges in positive and negative directions.

This type of machine has advantages of more safety in operation, easy in maintenance, high efficiency and lower labor intensity. It has been proved that bottle broken rate is less then 0.2%. So it is ideal equipment for beverage or beer factory.

2.Technical parameters

Specs of bottles	O.D. of bottle (mm)	58±1		64±1			75±1
	Bottle height (mm)	200±1.0		197±1.5			290±1.0
Washing efficiency	XP-I		XP-Ⅱ			XP-Ⅲ
	4000~4300 b/h		3000~3200 b/h			2800~3000 b/h
Main body of machine	Main motor				1.1kw
	Motor of inner brusher				0.55kw
	Speed of inner brusher				505 rpm
	Pressure of water supply				0.3MPa
	Speed of bottle feeding				7.24 m/min.
	Rotary speed of dialing wheel				7.28 s/r
	Overall dimension (L×W×H mm)				1700×1320×1300
	Weight (kg)				1000 kg
Outside brusher for removing label on bottles	Motor of conveyor				0.75kw
	Speed of conveyor				11.13 m/min.
	Motor of out- brusher				0.75kw
	Speed of out- brusher				700 r/min.
	Motor of pump				0.37kw
	Water consumption				2.8 m³/h
	Overall dimension (L×W×H mm)				2900×1920×1850
	Weight (kg)				600kg
Steeper	Temperature of solution				45~55°C
	Concentration of solution				NaOH 1.4%
	Overall dimension (L×W×H mm)				2100×1920×1850
	Weight				450kg
