Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Tile Making Machine > Forming
Forming
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Tile Forming Machine
Tile Type:
Colored
Use:
Step
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Tile Forming Machine
Tile Type
Colored
Use
Step
Brand Name
WILLING
Model Number
WLFM25-183-1110
Certification
CE
Specifications
We are specialied in making forming , we can design all kinds of pattern.Forming Features:
1) Consists of uncoiler and its base, coil sheet guiding equipment, film covered
device, roll forming system, pressing equipment, post-cutting equipment, hydraulic station, controlling system, supporter table
2) Material spec: colored and galvanized steel sheet at yield stress 33KSI
3) Thickness of coil sheet: 0.5 - 0.6 mm
4) Coil width: 1000mm5) Working speed: 3.0 - 4.0m/min (step distance at 380mm)
6) Power requirement: a) Main motor power: 7.5kW b) Hydraulic station power: 5.5kW
7) Passive uncoiler max. capacity: 5,000kg
8) Quantity of stands: 15 groups
9) Controlling system: PLC
10) Type of cutting: roll-formed and length-set cutting
11) Machine dimension: about 18,500 x 1,500 x 1,400mm
12) Total weight: about 9,500kg
13) Voltage: 380V 3 phase 60Hz or at buyer's requirement
14) Working flow: decoiling the sheet-sheet guiding-film covering-roll forming-measure length -pressing-cutting the panel-panels to the supporter
