Home > Products > CNC Cutting Machine > Start 7" Color Display Portable Cnc Cutting Machine-effective Cutting Area1500mmx3000mm
Start 7" Color Display Portable Cnc Cutting Machine-effective Cutting Area1500mmx3000mm
- Xingang
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | start | |
| Input Voltage | 220V, 220v | Usage | Sheet metal cutting |
Product Description
Specifications
c flame cutting machine2.1500mmX3000mm,1500mmX2500mm,1200mmX2000mm
3. 7" color display
4.Libraray with shapes
CNC Portable Plasma/Flame Metal Plate cutting machine
Specifications:
* The overall processing machine base: good stability, not deformed
* Using beeline and double-slide lead rails, high accuracy
* A detachable structural design for arm, convenient transportation and installation
* Beautiful structure, coordination, light weight;
* Machine base is made in steel.
* The CNC control system has the following character :
1) High reliability, such as anti-plasma jamming, and lightning strike, Surge;
2) 32M users program storage capacity can update to 64M;
3) In both English and Chinese interface conversion;
4) During plasma processing, auto-complete the speed control of the corner
5) Rich software features and practical flame / plasma cutting process;
6) In particular small line section procedure processing can be widely used in metal materials and advertisement, Iron;
7) Dynamic graphics zoom in 1-8X the graphics, fixed point of automatic tracking;
8) Using USB Flash Drive reading procedure and timely upgrade software;
9) Built-in the rich graphics, makes programming easy to learn.
100% test before shipping
Major Parameters:
Input Voltage | 220V |
Rated Power | 160W |
Power Frequency | 50HZ |
CNC control system | SH-2012AH-QG |
LCD Size | 7’’ Color Display |
Fuel Gas Source Pressure | Max. 0.1Mpa |
Oxygen Source Pressure | Max. 1.5Mpa |
Cutting Type | Flame or Plasma |
Cutting Speed (mm/min) | 50-1000 |
Cutting Thickness (Flame) | 3 - 150 mm |
Cutting Thickness (Plasma) | 0.1 – 50 mm (according to plasma source) |
Fuel | Propane, Acetylene, Methane |
Precision | 0.2 mm |
Cutting Nesting Software | IBE or FastCAM optional |
