Slitting Line for Sheet Coil

Slitting Line for Sheet Coil thumbnail-1
Slitting Line for Sheet Coil photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WILLNG
Contact Supplier Request Quote Chat Now
Hangzhou Willing International Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name WILLNG

Specifications

slitting line includes supportable table ,coil car, hydraulic uncoiler, sheet guiding equipment, leveling system.

Slitting Line Feature:

1)Material Spec:

galvanized steel sheet at stress 235Mpa (33ksi); less than 450Mpa.

2)Thickness:

0.3mm-3.0 mm

3)Coil width:

500-1600mm

4) Coil inner diameter:

508mm-610mm

5)Coil out diameter :

less than 2000mm

6) Max coil weight :

30T

7)Product coil inner diamer:

508mm

8) Product coil out diamter:

less than 1500mm

9) Product coil weight

 :

10T

10) Production speed:

0-120m/min

11)The slit width tolerance:

±0.05 at thickness 0.5-1.0mm ±0.1mm at thickness 1.1-2.0mm ±0.15mm at thickness 2.1-3.0mm

12)Slitting straighten tolerance:

0.2mm/m

13)The slitting burr:

less than 0.05mm

14) Min slit width:

30mm

15)The slit strip quantity:

20 strips

16)The waste edge:

3-15mm

17)The quantity of waste edge:

2strips

18)The Max weight of waste edge:

less than 150kgs/roll

19) The main power:

220kw

20)The weight of the line:

about 68T

21) The dimension of the line:

2500 0 mm*8500 mm





Slitting Line for Sheet Coilng Line,Slitting Line,Slitting Line
