high quality newest Dual-core Cpu Libertview f5
General Specifications
Dual-Core CPU, 396 MHz MIPS Processor
Fully compliant MPEG-4 H.264/AVC Main Profile Level 3 & High Profile Level 4.1;
Fully compliant MPEG-1 Layer I & II & III, Dolby Digital Audio(AC3);
SCPC & MCPC receivable from C/Ku band satellites;
multiple LNB-Switching control (supports DiSEqC1.0/1.1/unicable/1.2/1.3(USALS) supported)
NIT search supported;
Support MPEG-5;
Support HDMI 1.3;
Support PVR(store in USB disk);
Multimedia files playback(by USB);
Support Electronic Program Guide(EPG) for 7 days;
Teletext and subtitle out through OSD;
Support multi-lingual DVB subtitle and teletext;
Automatic and manual channel scan options;
automatic service scan
channel-change time < 1 second
OSD in many languages and skin-support
Multilingual support on screen menu (OSD): English, French, Deutsch, Italian, Spanish, Portuguese, Russia, Turkish, Polski, Arabic, Thailand, selectable
LED Display
Multiple display mode: 1080p/1080i/720p/570p/576i/480p;
MPEG-2 / H.264 Hardware decoding
Videotext Decoder
Analog audio output: stereo(L+R);
Screen format:auto, 4:3, and 16:9;
Upgrade software through USB2.0 port;
Powerful program management function, parent lock;
CA 1x slot
10/100Mbit Ethernet Interface
directly bouquet-lists
Board configuration 396MHz MIPS CPU
128MB DDRII400 RAM
Memory Clock 198MHz
4MB Serial Flash
Single Tuner
DVB-S2 demodulator
Power Supply Input 100V-240V 50/60Hz
Power Consumption 30W Max/1W Standby (it's optional by customer?s board)
RS232 For FW Upgrading
Standard Receiver Standard DVB-S2 Standard (DTSI EN 302 307)
Input Frequency Range 950MHz~2150MHz
Input Signal Level -25dBm ~ -65dBm
Demodulation QPSK, 8PSK, 16APSK
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
MPEG Profile Level MPEG-2 SD, MPEG-2 HD, H.264/AVC SD, H.264/AVC HD
LNB Power & Polarisation Vertical +13.5V, Horizontal 18V, Current: MAX 500ma
Multi Satellite Receiving 22K switcher, DiSEqC1.0, DiSEqC1.1, DiSEqC1.2, USAL
Conditional Access System 1 CA card reader Slots
A/V Output ports HDMI 1.3, Left/Right analog audio output(RCA)
Aspect Ratio Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box.
Audio Decoding MPEG1 Layer I, MPEG1 Layer II, MPEG 1 Layer III, MPEG2, AC3.
Audio Mode Stereo/MONO/Left/Right
DVR supporting DVR with USB HDD, Time shifting with USB HDD
USB2.0 High Speed Host 1USB2.0 Port, USB media player to playback the media in USB flash disk or USB HDD or USB card reader with memory card or FW Upgrading.
File System FAT12, FAT16, FAT32, NTFS
Media Supporting JPG, BMP, MP3, WMA
Ethernet Interface 10Mbit
Storage Temperature 0oC To +50oC
package
1x F5 HD Box
1x Remote control
1x Power Supply Cable
1x HDMI Cable
1x User Manual
