Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable thumbnail-3

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable thumbnail-4

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable photo-1

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable photo-2

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable photo-3

New Product GYHTY Non-metallic Strength Member Cable, Self-support GYHTY Fiber Optic Cable photo-4

US$ 0.1 - 5 MOQ: 1000 Meters

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

GYHTY

Contact Supplier Request Quote Chat Now

Shenzhen BLH Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number GYHTY

Type Coaxial

New product GYHTY Non-metallic Strength Member Cable, self-support GYHTY fiber optic cable

Description

The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular core. After the cable core is filled with filling compound, it is covered with thin PE (polyethylene) inner sheath. Then, a layer of aramid yarn is applied as additional strength member and the cable is completed with a polyethylene (PE) outer sheath.

Features

1.Good mechanical and temperature performance

2. Aramid yarn strength member ensures good performance of tensile strength

3.High strength loose tube that is hydrolysis resistant

4.Special tube filling compound ensure a critical protection of fiber

5.Crush resistance and flexibility

6. The following measures are taken to ensure the cable watertight:

7.Single Fiber Reinforced Plastic as the central strength member

8. Loose tube filling compound

9.100% cable core filling

Applications

GYHTY cable complies with Standard YD/T 901-2001as well as IEC 60794-1.

Specifications

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelengthλcc		≤1260nm	≤1480nm

Cable Type	Fiber Count	Tubes	Fillers	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static /Dynamic mm
GYHTY-2~6	2~6	1	5	11.0	100	600/1500	300/1000	10D/20D
GYHTY-8~12	8~12	2	4	11.0	100	600/1500	300/1000	10D/20D
GYHTY-14~18	14~18	3	3	11.0	100	600/1500	300/1000	10D/20D
GYHTY -20~24	20~24	4	2	11.0	100	600/1500	300/1000	10D/20D
GYHTY-26~30	26~30	5	1	11.0	100	600/1500	300/1000	10D/20D
GYHTY-32~36	32~36	6	0	11.0	100	600/1500	300/1000	10D/20D

Pictures

Payment and Delievery

Payment : L/C, T/T, Western Union, Moneygram,Paypal as well as Cash acceptable

Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
