2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine

2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine thumbnail-1
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine thumbnail-2
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine thumbnail-3
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine thumbnail-4
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine thumbnail-5
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine photo-1
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine photo-2
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine photo-3
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine photo-4
2016 Hot Sale High Efficiency High Quality Cone Mineral Stone Grinding Ball Mill Machine photo-5
US$ 10,000 - 100,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Yantai Jinpeng Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) 145-430kw
Capacity(t/h) 0.5-12t/h
Place of Origin Shandong, China
Brand Name JinPeng
Model Number ZTMG/ZTMY
Dimension(L*W*H) M) Dimension
Weight 34t~60T
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Specifications



Ball Mill
1.Simple structure
2. Easy adjustment and maintenance
3. Reliable operation
4.Less power consumption,low noise



Yantai Jinpeng Mining Machinery CO., LTD

Professional mineral processing design, equipment production,installation and conmissioning institue.

Tel: 0086-13153515710







Energy-saving ball mill grinding machine for mining



 Ball mill is widely used in mining, smelting,road,building material and chemical. It is the key equipment for grinding after the crush process.The mill consists of feeding device, driving assembly, rotating assembly,bearing unit,discharging assembly and foundation unit.There are two discharging type: wet grid ball mill and dry grid ball mill.



 <img src="/img/pb/129/494/596/596494129_737.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="169" height="36" ori-width="169" ori-height="36">





<img src="/img/pb/837/513/595/595513837_060.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="655" height="410" ori-width="655" ori-height="410"> <img src="/img/pb/121/494/596/596494121_436.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="180" height="48" ori-width="180" ori-height="48">

(1) Save energy: bush bearing is replaced by rolling bearing, friction resistance being greatly lowered down, easy to be started. It’s energy is lower 10-15% than the old one.

(2)Large capacity: for the outlet disk and the checked liner are adopted, the capacity is higher 20% than the cone ball mill.

(3)The discharging port slurry surface is low, slurry flow through rapidly, decrease ore over-grinding.

(4)Load of ball is large, big balls, small balls be loaded in, and small balls can’t be discharged, and can form good working conditions.

 <img src="/img/pb/213/494/596/596494213_625.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="248" height="37" ori-width="248" ori-height="37">



model

Cylinder diameter

Cylinder length

Rotary speed

Motor model

Motor power

Motor speed

Effective volume

Maximum load of ball

0909

900

900

37.1

Y180L-6

15KW

970

0.91

1.5

0918

900

1800

37.1

Y200L-8

15KW

740

0.91

1.5

1228

1200

2800

29.5

YR280S-8

55KW

725

2.8

5

1530

1500

3000

29.8

JR117-8

80KW

725

5

10

2130

2100

3000

24.05

JR136-8

180KW

735

9.0

18

2136

2100

3600

24

JR137-8

210KW

735

11

21.6

2140

2100

4000

24

JR138-8

245KW

735

12.1

23.5

2436

2400

3600

22.5

JR138-8A

280KW

743

14

26

2440

2400

4000

22.5

JR138-8B

320KW

743

15

26

2442

2400

4200

22.5

JR500L2-8

355KW

745

16

26

2445

2400

4500

22.5

JR500L3-8

380KW

745

17

29.5

2736

2700

3600

21.6

JR500L3-8

380KW

745

19.4

36





Pictures





<img src="/img/pb/425/233/634/634233425_578.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="578" height="516" ori-width="800" ori-height="600">



 <img src="/img/pb/112/448/600/600448112_235.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="585" height="456" ori-width="800" ori-height="600">



  Usually used in the following similiar process of gold,silver,copper, lead zinc, molybdenum and so on.



<img src="/img/pb/456/424/590/590424456_459.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="580" height="439" ori-width="800" ori-height="565"> <img src="/img/pb/215/494/596/596494215_074.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="180" height="48" ori-width="180" ori-height="48">



<img src="/img/pb/951/458/600/600458951_532.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="631" height="588" ori-width="800" ori-height="600">



 <img src="/img/pb/808/246/634/634246808_752.JPG" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="622" height="478" ori-width="800" ori-height="600">



 <img src="/img/pb/125/494/596/596494125_111.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="248" height="37" ori-width="248" ori-height="37">

Startup of ball mill

A. Check if all connecting bolts are tightened before startup of ball mill, and if there is any loosening with all connected parts.

B. Check if lubrication of oil site meet requirements.

C. Check if there is anything around ball mill and sorting machine, which may prevent the machines from running.

D. Startup sequence for devices of loop; start ball mill before sorting machine, followed by ore feeding after normal running.

Stop of grinding loop:

If grinding loop stops running, stop ore feeder first. Then stop ball mill after the ores are processed inside the drum of ball mill. Take out the screw axis of the sorting machine out of the sand surface. Stop the sorting machine finally.



 <img src="/img/pb/122/494/596/596494122_529.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="248" height="37" ori-width="248" ori-height="37"><img src="/img/pb/960/592/593/593592960_224.jpg" alt="2014 Hot Sale High Efficiency Mineral Stone Grinding Ball Mill Machine /powder Making Mill With Excellent Output Fineness" width="575" height="502" ori-width="737" ori-height="599">

Provide ore dressing experiment,process design and onsite engineering service.

<img src="/img/pb/111/564/589/589564111_835.jpg" width="448" height="514" ori-width="447" ori-height="497">





Welcome to visit our lab, design institute and factory!
