Help CenterDW330 Vinyl Cutting Plotter
Related Products
Specifications
vinyl cutting plotter1.easy-carry and easy-operate
2.CE certificate
3.with USB
DW330 vinyl cutting plotter
Features:
DW240/330 is a mini cutting machine placed on table, it can cut paper or plastic slice according to the pattern designed in computer, it has laser positioning device. It can accomplish cutting the outline sketch of the printed graphs.
It can cut vinyls, none dried glue labels, card papers, film papers. It is used to make paper models, joined graphs, stereo congratulation cards, name cards, cartoon stamps,etc.
It is delicate and cabinet, much appropriately used in stores,offices,schools and families, especially in Europe and America countries, many families buy it to help their children to enhance their intellectual faculties
Specifications:
|
Model Item |
DW240 |
DW330 |
Max.cutting range(mm) |
190×2000 |
290×2000 |
Material width |
A4 size |
A3 size |
N.W/G.W |
4.5/5.5 |
5.5/6.5 |
Measurement (mm) |
490×260×330 |
580×260×330 |
Available material |
PVC or lactoprene sheet (less than 0.1mm thickness),drawing paper,postcard,back-glue print paper,ink jet photo paper |
|
Operation environment |
Temperature:5°C-30°C Relative humidity:(35%-80%)without condensation |
|
Power supply |
Dedicated adapter ,DC 16V 2.5A Input :AC100V-240V; 47Hz-66Hz |
|
Cutting force |
60g to 350g (7 ranks optional) |
|
Cutting speed |
10 to 280mm/s (7grades optional) |
|
Configuration |
(Grit-rolling) |
|
Interface |
USB1.0 or RS232 |
|
Drive system |
Step motor |
|
Guarantee & After Sales Service
1) The machine guarantee period is 18 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
