Specifications
1.18000GPD Water Purification System2. Two-stage RO with PH control
3. Flocculant dosing
4. EDI
5. 10 year experience
About the Product
Project Name: 3m³/hr Ultra-pure Water System
Ultra-pure is widely used in areas such as biotechnology, pharmaceutical, automotive. There is hardly any impurity in ultra-pure water except H2O nor any bacteris, viruses, chlorine-diocxin, other organic compounds. It spares high reputation in the biotechnology field.
Application
- Semi-conductor
- TFT-LCD
- Fluorescent Lamp production process.
Treated Water Quality
- Resistivity >18MΩ.cm
- TOC< 10ppb
- SiO2 < 10ppb
- Particle 0.2µm≤3pcs/L
Main Parts in Water Purification System
- Flocculant dosing system
- Sand filter
- Carbon filter
- Softener
- 2 Pass RO with PH control
- Heat exchanger
- EDI
- Tank with Nitrogen balance device
- UV(185nm)
- Polisher Resin
- UF
Specification (Customized machines are availalbe, 3 ton--6 ton, 10 ton, 20 ton, e.g )
| Model | L/HR | Membrane | HP Motor | Phase | Piping | Approx. Dimension | |
| 150psi | 225psi | Inlet | L×W×H (cm) | ||||
| SERO-800 | 125 | 4021×1 | 0.55kw | 1.1kw | single | 1/2'' | 160×70×172 |
| SERO-1500 | 125 | 4040×1 | 1.1kw | 1.5kw | single | 3/4'' | 160×80×172 |
| SERO-3000 | 500 | 4040×2 | 1.1kw | 2.2kw | single | 3/4'' | 160×80×172 |
| SERO-4500 | 750 | 4040×3 | 1.1kw | 2.2kw | single | 1'' | 170×80×185 |
| SERO-6000 | 1000 | 4040×4 | 1.5kw | 2.2kw | three | 1'' | 190×90×185 |
| SERO-7500 | 1250 | 4040×5 | 1.5kw | 2.2kw | three | 1'' | 215×90×185 |
| SERO-9000 | 1500 | 4040×6 | 2.2kw | 3kw | three | 1-1/4'' | 230×90×185 |
| SERO-12000 | 2000 | 4040×8 | 2.2kw | 3kw | three | 1-1/4'' | 280×90×195 |
Company Profile
Compared with other brands, we are promised to our customer with High Quality, Competitive Price, Fast Delivery, Quick Response.
Advantages
- Dedicated to develop the clean water in China
- More than 10 years of experience
- Advanced technology abroad
- Specialized in dealing with the supply, technological consultant, assembly of commercial and industrial water treatment
- Full series of after-service
Main Products:
RO Water Treatment Plant/ CSM RO Membrane/Hydranautics Membrane/Dow membrane/ FRP Membrane Housing/SS Membrane Housing/ Fleck Valve/Fobrite Water Softener Control Valve, etc.
Products Pictures
1 T/Hr Water Purification System
Water Purification System installed in Container
Water Purification System with EDI (Electro-deionization)
New Design 3000GPD Water Purification System
800GPD Small Water Purification System
Valves and Tanks in Water Purification System
Softener Parts of Water Purification System
Membrane in Water Purification System ant
Control Valves in Water Purification System
