High Quality UV Water Sterilizer With CE Certification

High Quality UV Water Sterilizer With CE Certification photo-1
US$ 60 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
Aqua Best
Model Number:
AB series
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Taiwan, China
Brand Name Aqua Best
Model Number AB series

Specifications

1. AquaBest UV Water Sterilizer
2. SS 304/SS316 shell
3. Cabinet base with timer
4. Intensity monitor on request
5. CE&UL

AquaBest High Quality UV Water Sterilizer with CE Certification

About the Product



UV water disinfection system is a unique and  rapid method water disinfection without the use of heat or chemicals to effectively destroys bacteris, virus, mold.

UV light treatment is a widely recognized and proven method of disinfection of water and has several advantages over other disinfection methods such as chlorination, ozonation, etc. It does not add anything to the water, such as undesirable color, odor, taste or flavor, nor does it generate harmful buproducts. It adds only energy in the form of ultraviolet radiation. Also, UV disinfection requires only a fraction of the contact times required  by other disinfection methods. It is fast, efficient, effective, economical.



Application

  • Pharmaceutical                 ♦ Cosmetics
  • Semiconductor                  ♦ Aquaculture
  • Power generation              ♦ Healthcare
  • Food and beverage

Key Points to be mentioned

  • Multi lamps operation systems
  • Compact design with controller cabinet
  • Flow rate: 12gpm(45lpm) to 100 gpm(378lpm)
  • Hour meter, Lamp operating indicators, Audible alarm
  • Number of lamp/quartz sleeve/ballasts: 1 pcs to 8 pcs
  • UV lamp can be changed without interrupting the water flow
  • SS304 construction material, SS316 on request
  • CE certification
  • Max. Operating Pressure: 125 psi (8.63 bar)
  • Ambient Temperature: 2-40°C (36-104°F)
  • Iron<0.3ppm (0.3 mg/l)
  • Hardness<7gpg(120mg/l)
  • Turbidity<1NTU
  • UV Transmittance>75%
  • 4-Log (99.99%) Reduction in Bacteria, Viruses and Protozoan Cysts.
Specification

AB series Low-flow UV

Part No. Flow Rate Connection Quartz Sleeve(Length) UV lamp
AB-1A 1GPM/0.25TPH 1/2'' male threaded 245mm 10W×1
AB-2A 2GPM/0.5TPH 1/2'' male threaded 331mm 14W×1
AB-6A 6GPM/1.5TPH 3/4'' male threaded 460mm 24W×1
AB-8A 8GPM/1.8TPH 3/4'' male threaded 665mm 32W×1
AB-12A 12GPM/2.7TPH 1'' male threaded 890mm 39W×1

AB series Medium-flow UV
Part No. Flow Rate Connection Quartz Sleeve(Length) UV lamp
AB-12B 12GPM/2.7TPH 1'' male threaded 890mm 39W×1
AB-24B 24GPM/5.5TPH 1'' male threaded 890mm 39W×2
AB-35B 35GPM/8TPH 1.5'' male threaded 890mm 39W×3
AB-50B 50GPM/11.3TPH 1.5'' male threaded 890mm 39W×4
AB-60B 60GPM/13.5TPH 2'' male threaded 890mm 39W×5
AB-80B 80GPM/18TPH 2'' male threaded 890mm 39W×6
AB-100B 100GPM/22.5TPH 2'' male threaded 890mm 39W×8

Note:

  • 220/110V available
  • SUS 304 shell
  • Cabinet base with timer
  • Intensity monitor on request
  • CE&UL

Overview of Aqua Best UV Sterilizer

High Quality UV Water Sterilizer with CE Certification



Aqua Best UV Sterilizer AB Series and LT Series

High Quality UV Water Sterilizer with CE Certification



Main Products:

RO Water Treatment Plant/ CSM RO Membrane/Hydranautics Membrane/Dow membrane/ FRP Membrane Housing/SS Membrane Housing/ Fleck Valve/Fobrite Water Softener Control Valve, etc.
