Specifications
1.Paper Roll Slitting Rewinder2.Automatic Operation
3.High Quality Products
4.Superior Technical service
EDW-ISR Automatic Toilet Paper Machine is includes embossing, perforating , slitting and rewinding function. It uses pneumatic jumbo roll loading , pneumatic belt driving, web tension control devices. The winding rolls are of air expansion function. The whole machine is featured of easy operation and good winding profiles, making it an ideal equipment for the production of top quality industrial rolls.
Technical Specifications of paper roll slitting rewinder
Type |
EDW-ISR-1092 |
EDW-ISR-1575 |
Function |
Used to slit and rewind 1, 2, 3plies jumbo roll for difference gsm paper, non-woven, airlaid and raw apper. |
|
Product size |
≤φ1200 Width adjustable |
≤φ1200 Width adjustable |
Raw paper width(mm) |
up to 1100 x 1330 |
up to 1100 x 1800 |
Processing speed |
300m/min |
300m/min |
Control System |
1) PLC 2) Touch screen 3) Frequency conversion speed control |
|
Finished rolls diameter |
Automatic diameter control for finished rolls 500-1200mm |
|
Other features |
1) Emergency stop system 2) Manual feeding core unit 3) Pneumatic rewinding unit 4) Slitting width adjustable 5) Calendar unit is optioned 6) Cone wheel control web tension in manual |
|
Core diameter |
Manually adjustable, Min 50mm-76mm Max. |
|
Power |
4.5KW |
5.5KW |
Machine size (mm) (LxWxH) |
5300 x 3180 x1800 |
5300 x 3620 x 1800 |
Weight |
1800 kg |
2350 kg |
paper roll slitting rewinder
paper roll slitting rewinder
