Home > Electrical & Electronics > Electric Motor > DC Motor > 12V 16mm Low Voltage Graphite Brush Micro dc Electric Coreless Motor
12V 16mm Low Voltage Graphite Brush Micro dc Electric Coreless Motor
US$ 1 - 1,000
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
1640RCG -1-12.0
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
6mm 3V--6V Micro Coreless dc MotorUS$ 1 - 1,000MOQ: 100 Pieces -
30mm Graphite Brush Small Coreless DC Motor for MedicalUS$ 1 - 1,000MOQ: 10 Pieces
-
24V 25mm 2440rpm Performance Stable Coreless Motor,graphite Brush Slotless dc MotorNegotiableMOQ: 10 Pieces
-
7.4V 24mm Pernament Magnet Long Lifetime Graphite Brush Micro Coreless MotorsNegotiableMOQ: 10 Pieces
-
22mm High Precision Long Life Robot Carbon Brush dc Micro Coreless MotorNegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Constar
Model Number
1640RCG -1-12.0
Usage
Other, medical,health care and industrial automation., medical,health care and industrial automation.
Certification
CE, ROHS
Type
Micro Motor
Torque
6mNm
Construction
Other, precious metal commutation
Commutation
Brush
Protect Feature
Other, *
Speed(RPM)
6420rpm
Continuous Current(A)
688mA
Output Power
4.06W
Voltage(V)
12V
Efficiency
Other, *
12V 16mm low voltage graphite brush micro dc electric coreless motor
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series |
Performance Code |
Commutation Structure |
Dimension (mm) |
Voltage (V) |
Termanal resistence (Ω) |
No-load Speed (rpm) |
No-load Current (mA) |
Load Torque (mNm) |
Load Speed (rpm) |
Load Current (mA) |
1640RCG |
1-12.0 |
Graphile Brush |
Φ16*40 |
12 |
8.5 |
12000 |
60 |
6.0 |
6420 |
688 |
2-24.0 |
Graphile Brush |
Φ16*40 |
24 |
13.5 |
14500 |
60 |
8.0 |
10230 |
566 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
5,Photo:
