Home > Products > Coreless Motor > 7.4V 24mm Pernament Magnet Long Lifetime Graphite Brush Micro Coreless Motors
7.4V 24mm Pernament Magnet Long Lifetime Graphite Brush Micro Coreless Motors
Negotiable
/ Piece
10 Pieces(Min. Order)
- Shenzhen or HK
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
22mm High Precision Long Life Robot Carbon Brush dc Micro Coreless Motor
-
22*33mm Graphite Brush Long Life Precision PM Small dc Coreless Motor
-
24V Carbon Brush High Speed Precision Coreless Motor Used in UAV
-
16*45mm Graphite Brush Small dc Coreless Motor,long Lifetime Motors
-
16mm Graphite Brush dc Coreless Motor,Shenzhen Factory,can Custom Made
-
20*18mm No-load Speed 23000rpm Low Noise PMDC Coreless Motor
Product Details
| Place of Origin | Guangdong, China | Brand Name | Constar | |
| Model Number | 2430RCG -1S-7.4 | Usage | Other, medical,health care and industrial automation., medical,health care and industrial automation. | |
| Certification | CE, ROHS | Type | Micro Motor | |
| Torque | 5mNm | Construction | Other, precious metal commutation | |
| Commutation | Brush | Protect Feature | Other, * | |
| Speed(RPM) | 6630rpm | Continuous Current(A) | 691mA | |
| Output Power | 5.3W | Voltage(V) | 7.4V | |
| Efficiency | Other, * |
Product Description
7.4V 24mm pernament magnet long lifetime graphite brush micro coreless motors
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series | Performance Code | Commutation Structure | Dimension (mm) | Voltage (V) | Termanal resistence (Ω) | No-load Speed (rpm) | No-load Current (mA) | Load Torque (mNm) | Load Speed (rpm) | Load Current (mA) |
2430RCG | 1S-7.4 | Graphile Brush | Φ24*30 | 7.4 | 2.5 | 8350 | 100 | 5.0 | 6630 | 691 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
