FM Series Automatic High Speed Box Tissue Paper Converting Machine

Name: FM Series Automatic High Speed Box Tissue Paper Converting Machine
Brand: Elitis
SKU: 127115131
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Product Type:

Other, Box Tissue Paper Converting Machine

Processing Type:

Other, embossing printing packing machine

Place of Origin:

Guangxi, China

Nanning Elite Tissue Converting Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Product Type Other, Box Tissue Paper Converting Machine

Processing Type Other, embossing printing packing machine

Place of Origin Guangxi, China

Brand Name Elitis

Model Number FM-200-5T

Certification CE

Specifications

1 Box tissue paper converting machine
2 CE compliant
2 Customized printing&embossing
4 High speed
5 One year warranty

Technical parameters of Box Tissue Paper Converting Machine

Machine model	5 lanes; (Customized Up to 9 lanes.)
Use	Production of facial tissue machine or V fold hand towel
Sheet size	200 x 210 ± 2 mm; Other sizes please specify.
Folded size	100 x 210 mm ± 2/100 x 170 mm ± 2;
Parent Roll Size	210 x 3/630 x 1100 mm diameter
Parent Material	13-16g/m2 Two plies wood pulp tissue paper or others.
Raw material core diameter	3’’ (76.2 mm); Other sizes please specify.
*Folding speed*	*700-1000 pics/min x 5 lines or 160-200 m/min*
*Program control*	Frequency speed control; PLC; Electric inspection system
Embossing unit	Steel to rubber embossing; steel to steel embossing(optional).
Button embossing roll	Felt roller; paper roller; rubber roller(optional).
Edge embossing; Calendaring	Optional
Web guiding system	Optional
Air pump power	7.5-30 KW
Pneumatic system	3 HP air compressor; mini pressure 5 kg/cm2 pa (Provided by client).
Main motor power	5.5-11 KW
Machine Size	4800 x 1800 x 2100 mm
Weight	1500 KG
