Specifications
Ceramic fiber boardhigh density ceramic fiber board
ceramic fiber board for furnace wall insulation
Ceramic Fiber Board Descreption:
Ceramic Fiber Board Specifications
ceramic fiber board are made from refractory ceramic fiber, attending inorganic and suitable organic binders. The mixture is vacuum processed into boards or formed shapes that keep good mechanical strength after heating. These products can be manufactured using five basic fiber types: ISOFILE CFB Board, classification temperature 1000°C, 1260°C, 1400°C, 1600°C and 1700°C; and MB millboard, classification temperature 1500°C. ISOFILE CFB can be used for internal lining of furnace with high strength and anti airspeed eroding.
Ceremic fiber board Characteristic
- Smooth surface
- Low impurity, and average bulk density and thickness
- Excellent mechanical strength and structural strength
- Low thermal conductivity
- Low shrinkage
Ceramic Fiber Boards Applications
- Back-up lining of high-temperature industry furnaces.
- Hot-face lining of ceramic kilns, heat-treatment furnaces and other industrial kilns.
- Insulation for furnace door and kiln ca
|
Products Items |
STD Grade |
High Pure Grade |
High Aluminium Grade |
Zr Grade |
Specification Temperature () |
1260 |
1260 |
1360 |
1430 |
Working Temperature () |
1050 |
1100 |
1200 |
1350 |
Colour |
white |
white |
white |
white |
Bulk Density (kg/m3) |
240 - 320 |
240 - 320 |
240 - 320 |
240 - 320 |
|
Permanent Linear Shrinkage (24hr, Bulk Density 320kg/m3) |
- 4% (1000) |
- 4% (1100) |
- 4% (1250) |
- 4% (1350) |
|
Thermal conductivity (w/m.k) (Bulk Density 285kg/m3)
|
0.085 (400) |
0.085 (400) |
0.085 (400) |
0.085 (400) |
0.132 (800) |
0.132 (800) |
0.132 (800) |
0.132 (800) |
|
0.180 (1000) |
0.180 (1000) |
0.180 (1000) |
0.180 (1000) |
|
Crushing Strength (Mpa) |
0.5 min |
0.5 min |
0.5 min |
0.5 min |
Chemical Composition |
||||
Al2O3 |
45% - 46% |
47% - 49% |
52% -55% |
39% - 40% |
Al2O3 + SiO2 |
96% - 97% |
98% - 99% |
99% min |
--- |
Al2O3 + SiO2+ZrO2 |
--- |
--- |
--- |
99% min |
ZrO2 |
--- |
--- |
--- |
10%-18% |
Fe2O3 |
1.0% max |
0.5% max |
0.5% max |
0.2% max |
Na2O + K2O |
0.5% max |
0.2% max |
0.2% max |
0.2% max |
Regular Size (mm) |
600 x 400 x 10 5900 x 600 x 20 - 50 |
|||
Ceramic Fiber Board service
We can guarante e the quality of theceramic fiber board with the competitive price. We will try our best to satisfied the requirement of the customer about theceramic fiber board products. We do not want to do the one-shot business of theceramic fiber board. We also can provide some samples of the ceramic fiber board products.
