features:
1.extruder and tractor all adopt frequency conversion control system,which has the characteristics of easy operation,reliable running,stable working and low energy consumption.
2.screw and bolt of the extreder adopts special design,and it features excellent plasticationg capacity and stable production.
3.extruder and mold adopt sutomatic temperature control system so that the temperature-controlling is exact and also it can save energy effectively
4.unique vacuum control device,precise vacuum degree control,small micro-spraying tape diameter error.
control device adopts servo motor control, control accuracy is high.position error is small.
6.punch on the hole drilling machine is made of special steel and it has long service life.
7.holedrilling machine adopts advanced servo unit control,human-computer interface operation,punching accuracy is high,water outlet space error is small.high degree of automation.
8.double-station winder make changing roll is convenient and quick,and equip the meter-counting device,rolling length can be settled by self( ≤200m).after reaching setting length,it will be alarming.
| item | technical parameter | ||
| model | SJWP-60 | specification | φ25- φ75 |
| screw diameter | φ60mm | main driving power | 18.5kw |
| max.extruding capacity | 50kg/h | filter changing way | durable filter |
| traction motor | 1.5kw | winding motor | 0.75kw*2 sets |
| installation power | 48kw | production speed | ≤35m/min |
| overall dimension(L*W*H) | 11m*2.25m*3.6m | ||
irrigation tape making machine packaging:
Standard seaworthy packing wooden box,in order to prevent due to External force damaged during shipping,the goods used to strong wooden case.
China Tangshan Zhifu Plastic Machinery Co.,Ltd was established in 1986,lies in the southeast of Beijing and about 110kilometers away from Beijing with convenient transportation,It is knowledge-based,scientific and technological enterprise for special-purpose plastic machinery integrating design,develop,manufacture and service with advanced equipment,perfect monitoring method and strong technological foundation,The company was awarded the Advanced Technology Enterprise by china ministry of Science and Technology,it is also the member of National Commercial and Industrial Association and awarded the honor for seceral times.The company has import-export authority independently and passes the certificate of ISO9001 quality System and European Union CE Certificate.
our company is in the leading position of water-saving irrigation fields,we are the pioneer enterprise for making drip irrigation equipment in China and we have more than ten years histories of manufacturing the drip irrigation equipment.We take the lead of improving and using several practical and new-type technologies.We are the largest manufacturer and seller of drip irrigation equipment in china and world. From 2003 till now,we have sold the drip irrigation tape making machine we sold reach more than 2200 sets.Our products have been distributed throughout the country and also exported to Europe,Americas,Middle Esat,and Southeast Asia etc.over thirty countries and regions,The superior quality, favorable price and perfect after-sales service make the products be well received at home and abroad.
