NDS Series Digital Display Material Torsion Testing Machine
- 400 Set / Sets per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | HST | Model Number: | NDS Digital Display Material Torsion Testing Machine |
Power: | Electronic | Usage: | Torsion Tester |
Product Description
NDS Series Digital Display Material Torsion Testing Machine
Phone/whatsapp:+86-15069028022 Skype: hstbetty009
NDS Series Digital Display Material Torsion Testing Machine
1. Application:
This series materials torsion testing machine is used for torsion test of metal materials, nonmetallic materials, composite materials and components
2. Standard:
GB/T 10128-1998 “Meta torsion test methods under room temperature”
GB/T 10128-2007 “Meta torsion test methods under room temperature”
3. Technical parameter:
Model | NDS-200 | NDS-500 | NDS- 1000 | NDS- 2000 | NDS- 3000 | NDS- 5000 |
Max torque(N/m) | 200 | 500 | 1000 | 20000 | 3000 | 5000 |
Test class | 1 class | |||||
Control method | single chip control | |||||
Torque test range(F·S) | 2%~100%F·S | |||||
Torque value accuracy | ≤±1 | |||||
Torque display resolution | 1/5000 | |||||
Angle value accuracy (%) | ≤±1 | |||||
Angle display resolution(°) | 0.01 | |||||
Max torque angle | 99999° | |||||
Torque angular rate control rang(°/min) | 0.05-800 | |||||
Effective distance between chucks (mm) | 600 | |||||
Test rotating direction | Two ways | |||||
Power | 220V±10%,50Hz |
4. Features:
1. Automatic stop:After the sample broke, the moving beam automatically stop
2. Display mode:During the test process, real time display the torque force, torque angle, torque speed, peak value, and test condition and others displayed in the same LCD screen;
3.Limit protection:with stored program control (SPC ) and mechanical two level limit protection
4.Overload protection: When more than 3 ~ 5% of the rated load device automatically stop working When the load over
5. Configuration
1. High strength torque testing machine host(Table structure, spraying plastic processing machine-- 1pc
2. High precision angle encoder-- 1pc
3. High precision AC servo control system and AC servo speed regulating motor--1set
4. Taiwan ABBA precision linear guide--2 sets
5. High efficient needlework balance wheel reducer -- 1set
6. High precision torque sensor--1pc
7. Special torque grip--1 set
8. HST-N600 Torsion testing machine special test and control system--1 set
NDS Series Digital Display Material Torsion Testing Machine
