EZ Metal Wire Torsion Test Machines, Digital Display Wire Torsion Testers
- 500 Set / Sets per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | HST | Model Number: | EZ Wire Torsion Testing Machine |
Power: | Electronic | Usage: | Torsion Tester |
Product Description
EZ Metal Wire Torsion Test Machines, Digital Display Wire Torsion Testers
ALI: cn1510988092 Phone/whatsapp:+86-15069028022 Skype: hstbetty009
EZ Metal Wire Torsion Test Machines, Digital Display Wire Torsion Testers
1. Application:
Wire torsion testing machine applies to determine the ability of diameter(or feature size) of 0.1-20.0 mm wire for bearing plastic deformation in one way or two way reverse, display the surface and internal defects of the wire .Widely used in aerospace, metal material processing, tire manufacturing industries, and institutions of higher learning, scientific research institutions, technical supervision, quality inspection station and other departments.
2. Standard :
GB/T2611-2007 General Requirements for Testing Machines
GB/T 239-1999 Metal wire twisting test method
ISO 7800:1984 Metal wire one-way torsion test method
ISO 9649:1990 Metal wire two-way torsion test method
3. Product Features
1) One-way reverse: the sample around its own axis in one direction as a uniform 360 ° rotation to a specified number of times or reverse specimen fracture;
2) Two-way reverse: the sample evenly around its own axis 360 ° rotation in one direction as a reverse to the specified number of times, the same number of times in the opposite direction of rotation or specimen fracture;
3) The number of settings: You can pre-set the number of samples to reverse automatically shut down after arrival;
4) Adjustable rotation speed: speed motor, speed rotary switch;
5) Display: digital real-time display.
4. Technical parameter:
Model | EZ-3 | EZ-10 |
Work Method | Auto-loading | |
Max. Clamp metal wire diameter (mm) | 0.2-3.0 | 1-10 |
Parallelism of the full moving guide | ≤0.2 | |
Max. distance of two chucks (mm) | 320 | 520 |
Rotation speed adjusting range (r/min) | 0-180 | 0-60 |
Velocity error | <±1% | |
Min. number of circle values | 0.1 | |
Two chuck alignment(mm) | <0.4 | |
Jaw hardness(HRC) | 55-65 | |
Farmar error | ±0.5% | |
Work Noise (dB) | ≤70 | |
Min. revolutions reading values(r) | 1 | |
Power Supply | AC 220V±10%,50Hz |
Wire Torsion Tester, Steel Wire Torsion Test Machine
'
1.Shipping & delivery:
It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine' Packaging:
Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
♥ Main web site: : http://www.
